Multifunction Time Delay Relay, Octal, Multi Function, 16 Functions 120V AC, SPDT

  • Mfr # TD-88162

  • Zoro # G3631774

CAD Available
product price:  $85.15
/ea

Key Features

CAD Drawing
Delay Function
Multi Function
Number of Delay Functions
16
Minimum Time Setting
0.05 sec
Maximum Time Setting
10,230 hr
Base Shape
Octal
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
TD-88162
Zoro #
G3631774
UPC #
801262039971
Country of Origin
United States

Dimensions

Overall Height - Relay
3 in
Overall Depth
3.03 in
Body Width
2.33 in
Body Height
1.77 in
Body Depth
2.9 in

Details

Item
Multifunction Time Delay Relay
Delay Function
Multi Function
Number of Delay Functions
16
Minimum Time Setting
0.05 sec
Maximum Time Setting
10,230 hr
Base Shape
Octal
Number of Pins
8
Coil Voltage
120V AC
Current Rating
10 A
Contact Form
SPDT
Contact Rating (AC)
10 A @ 240V AC
Contact Rating (DC)
10 A @ 30V
Contact Material
Silver Nickel
Status Indicator
LED
Number of Functions
16
Socket
1EGP3, 1EGP5, 5X852
Contact Amp Rating (Resistive)
10A
Coil Rating
2VA
Standards
CE Certified, CSA Certified, UL Listed, UL Socket
Operating Functions
1, 2, 3, 4, 5, 6, 7, 9, + 8 Others
Socket Code
B
Electrical Connection
Socket
Adjustment Method
Dip Switch
Input Voltage
120V AC/DC
Electrical Operating Durability
100,000
Adjustment Interface
Digital
IP Rating
IP20
Power Consumption
2 VA
Frequency
50/60 Hz
Minimum Operating Temperature
-18 Degrees F
Reset Method
Time-Limit Reset
Maximum Operating Temperature
149 Degrees F
Sealing
Enclosed
Mounting Style
Plug-In
Operating Time Accuracy
+1% +50ms
Mechanical Operating Durability
10,000,000
CAD Available
Yes

Description

Multi-Function Time Delay Relay, Adjustment Method Dip Switch, Base Shape Octal, Coil Voltage 120V AC, Contact Form SPDT, Contact Rating (AC) 10 A @ 240V, Contact Rating (DC) 10 A @ 30V, Current Rating 10 A, Number of Delay Functions 16, Delay Function Multi Function, Electrical Connection Socket, Flat Pin Width Not Applicable, IP Rating IP20, Input Voltage 120V AC/DC, Minimum Time Setting 0.05 sec, Maximum Time Setting 10,230 hr, Number of Pins 8, Sealing Enclosed, Mounting Style Plug-In
