Megger Circuit Breaker Finder, Digital, 60 Hz MCT105 - main

Circuit Breaker Finder, Digital, 60 Hz

  • Mfr # MCT105

  • Zoro # G115093970

product price:  $286.99
/ea
Free Shipping & Returns

Key Features

Includes
Receiver, Transmitter
Features
Auto Power Off, Automatic or Manual Sensitivity Adjustment, Built-In Torch (Receiver), Identify Fuses and Circuit Breakers, Locate Conductor Breaks and Short Circuits, Low Battery Indicators, Non-Contact Voltage Detector (Receiver), Trace Cables and Conductors in Walls, Trace Conductors Buried in the Ground, Trace Metal Water and Heating Pipes, Works on Both Live and Dead Cables or Conductors
Operating Frequency
60 Hz
Power Source
Battery
For Circuit Type
Energized, Non-Energized
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
MCT105
Zoro #
G115093970
UPC #
5036175242629
Country of Origin
China

Dimensions

Receiver Dimensions
1.5 in x 2.4 in x 7.5 in
Transmitter Dimensions
1.25 in x 2.7 in x 5.1 in
Battery Size
9V
Maximum Locating Depth
8.2 ft
Test Lead Length
3 ft

Details

Item
Circuit Breaker Finder
Includes
Receiver, Transmitter
Features
Auto Power Off, Automatic or Manual Sensitivity Adjustment, Built-In Torch (Receiver), Identify Fuses and Circuit Breakers, Locate Conductor Breaks and Short Circuits, Low Battery Indicators, Non-Contact Voltage Detector (Receiver), Trace Cables and Conductors in Walls, Trace Conductors Buried in the Ground, Trace Metal Water and Heating Pipes, Works on Both Live and Dead Cables or Conductors
Operating Frequency
60 Hz
Power Source
Battery
For Circuit Type
Energized, Non-Energized
Tracing Locations
Walls
CAT Safety Rating
CAT III 300V
Energized Line Overload Protection
400V AC
For Voltage Range
12 to 400V AC/DC
Tracer Type
Circuit Breaker Finder
Number of Batteries Required
2
Alert Type
Light, Audible
Display Type
Digital
Testing Functions
Circuit Breaker Identification, Locate Fuses
Receiver to Transmitter Distance
1,000 m
Maximum Resistance
20 ohm
Display Screen Type
LCD
Standards
IEC EN61010-1
Circuit Connection Type
Alligator Clips, Test Probes
Signal Output Current
125 kHz
Energized Line Overload Protection Voltage
400 V AC

Description

Circuit Breaker Finder, Alert Type Light, Sound, CAT Safety Rating CAT III 300V, Display Screen Type LCD, Display Type Digital, For Circuit Type Energized, Non-Energized, For Voltage Range 12 - 400 V Test Range, 400 V AC/DC (max), Maximum Locating Depth 8.2 ft, Maximum Resistance 20 ohm, Operating Frequency 60 Hz, Receiver to Transmitter Distance 1,000 m, Tracing Locations Walls, Standards IEC EN61010-1
