ResistanceTester, 3mA, 30VAC/DC, Briefcase

  • Mfr # 1016-091

  • Zoro # G821672872

product price:  $7,377.99
/ea
Free Shipping & Returns

Key Features

USB Data Download Included
No
Tool Width
11.2 in
Pass/Fail Selection Limits
No
Maximum AC Voltage Measured
660 V
Power Source
Battery
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
1016-091
Zoro #
G821672872
UPC #
-
Country of Origin
United Kingdom

Dimensions

Tool Width
11.2 in
Tool Height
7.1 in
Tool Length
12.4 in

Details

USB Data Download Included
No
Pass/Fail Selection Limits
No
Maximum AC Voltage Measured
660 V
Power Source
Battery
Standards
IEC61010-31:2008
Minimum AC Current Measured
0.01 nA
Remote Test Probe Included
No
Waterproof
Yes
PI/DAR Testing
Yes
CAT Safety Rating
CAT IV 600V
Minimum DC Voltage Measured
30 V
Installation Tester Socket Region
EU, US
Minimum Operating Temperature
-4 Degrees F
Live Circuit Voltage Measurement - Maximum
660 V AC/DC
Number of Batteries Required
1
Display Screen Type
LCD with Backlight
IP Rating
IP40, IP65
Includes Software
Yes
Minimum AC Voltage Measured
30 V
Instrument Style
Briefcase
Maximum Operating Temperature
122 Degrees F
Alert Type
Digital Display, Audible
Resistance Accuracy
+/-20% up to 500 G Ohms, +/-5% up to 50 G Ohms
Minimum DC Current Measured
0.01 nA
Dustproof
Yes
Maximum Insulation Resistance
20 teraohm
Maximum DC Current Measured
3 mA
Auto Power Off
Yes
Maximum DC Voltage Measured
10 kV
Number of Digits
4
Capacitance Auto Discharge
Yes
Operating Voltage
1,000V; 10,000V; 2,500V; 250V; 5,000V; 500V; User Defined Test Voltage
Test Voltage
1,000V DC, 10,000V DC, 2,500V DC, 250V DC, 5,000V DC, 500V DC
Minimum Insulation Resistance
10 kiloohm
Timed Ramp Voltage Test
Yes
Data Logger
No
Testing Functions
Insulation Resistance
Calibration Certificate Included
Traceable without Data
Live Circuit Voltage Measurement - Minimum
30 V AC/DC
Backlit Digital Display
Yes
Data Output Type
No Output
Auto Ranging
Yes
Maximum Capacitance Measured
25 uF
Leakage Current Range
0.01 nA To 6 mA
Includes
Medium & Large Clips
Test Current
3 mA
Insulation Resistance Resolution
10 k Ohms to 20 T Ohms @ 10 kV
Insulation Limit Alarm
Yes
Display Type
Digital
Features
In Addition, the Test Mode Can Be Used to Ensure Dangerous Return Voltages Do Not Occur, Megger's PI Predictor(TM) Reduces PI Test Duration by upto 50%, Boosting Productivity when Testing Multiple Phases, MIT515 (Up to 5 kV) and MIT1015 (Up to 10 kV), Both Supporting Insulation Resistance, Dielectric Absorption Ratio (DAR) and Polarisation Index (PI) Testing, The High-Performance Guard Terminal Ensures Measurement Accuracy Even in High-Leakage Conditions, The New Innovative Patent Applied Re Greater ThanAct Test Mode Allows the User to Make Accurate Measurements by Monitoring Reabsorption Current, These Instruments Have No Onboard Storage and a Fixed 3 mA Burn/Charge Current - Perfect for Environments where Advanced Features like Remote Control aren't Required, This Groundbreaking Test Mode can Ensure Reabsorption Current Does Not Result in Incorrectly Passing or Failing Insulation, Helping to Maintain Safety
Greater Than 30V Warning
Yes
Maximum AC Current Measured
3 mA
Minimum Capacitance Measured
10 nF

Description

Resistance Tester, Backlit Digital Display Yes, Bluetooth Compatible Yes, CAT Safety Rating CAT IV 600V, Capacitance Auto Discharge Yes, Display Type Digital, Dustproof Yes, Greater Than 30V Warning Yes, Includes Medium & Large Clips, Insulation Limit Alarm Yes, Maximum Insulation Resistance 20 teraohm, Minimum Insulation Resistance 10 kiloohm, PI/DAR Testing Yes, Pass/Fail Selection Limits No, Power Source Battery, Remote Test Probe Included No
