  6. Pin & Sleeve Receptacle, 150 A, 208V AC, 2 Pole, Screw Terminals Wire Connection Type Blue, NEMA 4X

This item is Discontinued.

Meltric Pin & Sleeve Receptacle, 150 A, 208V AC, 2 Pole, Screw Terminals Wire Connection Type Blue, NEMA 4X 39-94232-K16

Pin & Sleeve Receptacle, 150 A, 208V AC, 2 Pole, Screw Terminals Wire Connection Type Blue, NEMA 4X (Discontinued)

  • Mfr # 39-94232-K16
  • Zoro # G201759537
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
39-94232-K16
Zoro #
G201759537
UPC #
784474679268
Country of Origin
United States

Dimensions

Wire Strip Length
Phase: 1-3/16 in (30 mm)
Use With Installation Accessory Size
5
Wire Size
4 AWG to 2/0 AWG

Details

Item
Pin & Sleeve Receptacle
Current Rating
150 A
Voltage Rating
208V AC
Number of Poles
2
Number of Wires
3
IP Rating
IP66, IP67, IP69
NEMA Enclosure Rating
4X
Wire Connection Type
Screw Terminals
Housing Color
Blue
Cap Type
Flip-Up Cap
Standards
cCSAus, 155873, C22.2 No. 182.1-13, E79796, UL 1682
Resistance Properties
Corrosion Resistant, UV AC/Sunlight Resistant, Watertight
Body Material
Aluminum
Use With
Mating Box MB10
Load Break Amp Rating
150A
Tightening Torque
Phase: 90 IN-LBS / 10.2 N-M
Wire Temperature Rating
60 Degrees C
Short Circuit Current Rating
100 KA - MAKE & WITHSTAND
Impact Rating
IK10
Number of Notch Positions
24
Operating Temp. Range
-40C to 60C
Keying Position
23
Contact Configuration
2P+G
Number of Aux. Outputs
NO AUX
Color Code
Blue
Hz
60 Hz
Load Break Amp Rating_Abnormal Overload
225A
Flange Type
Flanged

Description

DR150 RECEPTACLE METAL BLUE SIZE 5 TYPE 3R 2P+G 150A 208 VAC 60 Hz NO AUX
