Mepco Steam Trap, 1" NPT Outlet, SS Disc 4DS-8N - main

Steam Trap, 1" NPT Outlet, SS Disc

  • Mfr # 4DS-8N

  • Zoro # G0581198

product price: $330.99
/ea
Free Shipping & Returns

Key Features

(F)NPT Connections
1 in
Max. Operating PSI
600 psi
Disc Material
Stainless Steel
End to End Length
3 5/16 in
Condensate Capacity Lbs/Hr
2,820 lb/hr
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
4DS-8N
Zoro #
G0581198
UPC #
-
Country of Origin
United States

Dimensions

End to End Length
3 5/16 in
Port Connection Size
1 in
Overall Length
3 5/16 in

Details

Item
Steam Trap
(F)NPT Connections
1 in
Max. Operating PSI
600 psi
Disc Material
Stainless Steel
Condensate Capacity Lbs/Hr
2,820 lb/hr
Max. Temp.
800 Degrees F
Body Material
Stainless Steel
NPT Inlet
1 in
Pressure Air Vent
Releases Air and Non-Condensable Gases that Adversely Affect the Heat Transfer of a Steam System
NPT Outlet
1 in
NPT Port
1 in
Downstream PSI Range
0 to 595 psi
Application
Steam
Includes
Strainers
Type
Disc
Trap Position
Horizontal
Pipe Configuration
Straight
Condensate Capacity
2,820 lb/hr
Operating Temperature - Maximum
800 Degrees F
Port Connection Type
NPT
Number of Ports
3
Includes Strainer
Strainer Included
Operating Pressure - Minimum
0 psi
Steam Trap Type
Thermodynamic
Operating Pressure - Maximum
600 psi
Actuator Material
Stainless Steel
Cap Material
Stainless Steel
Installation Orientation
Horizontal
Includes Air Vent
Air Vent Included
Port Types Included
Inlet, Outlet
Configuration
In-line
Resistance Properties
Corrosion Resistant
Port Connection Gender
Female
Distance Between Inlet and Outlet Port
3 5/16 in

Description

Steam Trap, Actuator Material Stainless Steel, Application Steam, Body Material Stainless Steel, Cap Material Stainless Steel, Condensate Capacity 2,820 lb/hr, Configuration In-line, Distance Between Inlet and Outlet Port 3 5/16 in, Includes Air Vent Air Vent Included, Includes Strainer Strainer Included, Installation Orientation Horizontal, Number of Ports 3, Operating Pressure - Maximum 600 psi, Operating Pressure - Minimum 0 psi, Operating Temperature - Maximum 800 Degrees F
