Open Fuse Block, T UL Class, 600V AC/DC Volt Rating, 2 Poles, Box Lug

  • Mfr # 61032T
  • Zoro # G2893886

product price:
$
214.99
/ea
Free Shipping & Returns

Key Features

UL Class
T
Series
6TFB
Voltage Rating
600V AC, 600V DC
Connector Type
Box Lug
Mounting Style
Bolt-Down
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
61032T
Zoro #
G2893886
UPC #
782001675622
Country of Origin
Mexico
Item
Open Fuse Block
UL Class
T
Series
6TFB
Number of Poles
2
Amp Range
61 to 100A
Voltage Rating
600V AC, 600V DC
Connector Type
Box Lug
Mounting Style
Bolt-Down
Visual Indication
Non-Indicating
Fuse Block Style
Non-Rejection
Spring Reinforced Clip
Yes
Fuse Block Design
Open
Body Material
Phenolic
For Fuse Series
A6T
Standards
CSA Certified, UL Listed
Fuse Type
Industrial
Features
Adder Block Design
Wire Range
6 AWG to 2 AWG
Fits Fuse Type
Class T
Max. Operating Temp.
80 deg C
Frequency Range (Hz)
50/60 Hz
Short Circuit Current (KA)
200 kA
Fits Fuse Block Style
Non-Rejection
Fuse Block or Holder DC Voltage Rating
600VDC
Installation Mounting
Direct Screw Mount
Max Fuse Rating
100 A
Short Circuit Current Rating (SCCR)
200
Short Description
Fuse Bases 600V 100A Class T 2-pole Tin-Plate Aluminum Box
Rated Torque (In.-Lb.)
120 lb-in
Fuse Block or Holder AC Voltage Rating
600VAC
Fuse Installation Method
Clip-in
APPROVALS & STANDARDS
All fuse blocks meet the requirements of UL 4248; UL listed, guide IZLT, File E52283; UL recognized component guide IZLT2, file E52283; CSA certified class 6225, File 32169
DC Voltage Rating
600 V DC
Current - Maximum
100 A
Current - Minimum
61 A
AC Voltage Rating
600 V AC

Dimensions

Wire Size
6 to 2/0 AWG
Height
1.95 in
Width
3 in
Length
4.78 in
For Fuse Size
2-15/16 in L x 13/16 in dia, 2-61/64 in L x 3/4 in dia
Mounting Hole Dia.
0.19 in
Overall Height
1.95 in
Overall Length
4.78 in
Wire Size - Minimum
6 AWG
Wire Size - Maximum
2/0 AWG
Overall Width
3 in
Wire Rope Length
4.78 in
Fits Chest Size
Adder Block Design

Description

Fuse Block, Fits Fuse Type Class T, Fuse UL Class T, 61 to 100 A, Number of Poles 2, 600V AC/DC, For Fuse Size 2 15/16 in L x 13/16 in dia, 2 61/64 in L x 3/4 in dia, Compatible Fuse Series A6T; JJS; JLLS; LPT, Series 6TFB, Non-Indicating, Non-Rejection, Fuse Block Design Open, Wire Range 6 to 2/0 AWG, Mounting Style Bolt-Down, Body Material Phenolic, Connector Type Box Lug, Height 1.95 in, Width 3 in, Length 4.78 in, Spring Reinforced Clip Yes, Features Adder Block Design
