PowerDistributionBlock, 175A, 1000V, 2Poles

  • Mfr # MPDB66572

  • Zoro # G423720681

product price:  $147.99
/ea
Free Shipping & Returns

Key Features

For Line Copper Wire Size - Minimum
14 AWG
For Conductor Material
Copper
Maximum Current - Copper Conductor
175 A
Load Side Connection Type
Lug
Standards
CSA, National Electrical Code, UL, UL 1953, UL508A
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
MPDB66572
Zoro #
G423720681
UPC #
0782001454203
Country of Origin
Mexico

Dimensions

For Line Copper Wire Size - Minimum
14 AWG
Overall Length
78.2 mm
For Load Copper Wire Size - Maximum
14 AWG
Overall Width
90.7 mm
For Line Copper Wire Size - Maximum
2/0 AWG
Overall Depth
82.6 mm

Details

For Conductor Material
Copper
Maximum Current - Copper Conductor
175 A
Load Side Connection Type
Lug
Standards
CSA, National Electrical Code, UL, UL 1953, UL508A
Special Features
Mersen Power Distribution Blocks Provide a Safe and Easy Method of Splicing Cables, Splitting Primary Power into Secondary Circuits and Fulfilling Requirements for Fixed Junction Tap-Off Points
Power Distribution Block Design
Open
Maximum Voltage
1,000 V
Line Side Connection Type
Lug
Terminal Material
Copper
UL 94 Flammability Rating
V-0
Line Connections/Pole
1
Housing Material
Glass Filled Polycarbonate
Number of Poles
2
Primary Wire Range
2/0-#14
Load Connections/Pole
4
Secondary Wire Range
#2-#14
Item
Power Distribution Block

Description

Power Distribution Block, For Conductor Material Copper, Line Connections/Pole 1, Line Side Stud Size Not Applicable, For Line Copper Wire Size - Minimum 14 AWG, For Line Copper Wire Size - Maximum 2/0 AWG, Load Connections/Pole 4, Load Side Stud Size Not Applicable, For Load Copper Wire Size - Minimum Not Applicable, For Load Copper Wire Size - Maximum 14 AWG, Maximum Current - Copper Conductor 175 A, Maximum Voltage 1,000 V, Mounting Type Surface, Number of Poles 2, Overall Depth 82.6 mm
