  11. Surge Protection Device, 3 Phase, 240V AC, 3 Poles, 4 Wires
Mersen Surge Protection Device, 3 Phase, 240V AC, 3 Poles, 4 Wires STP240D07 - main

CAD Viewer & Download Files

Surge Protection Device, 3 Phase, 240V AC, 3 Poles, 4 Wires

  • Mfr # STP240D07

  • Zoro # G1606690

CAD Available
product price: $242.99
/ea
Free Shipping & Returns

Key Features

CAD Drawing
Mounting Style
DIN Rail
Phase
3
Voltage
240V AC
Number of Poles
3
Voltage Protection Rating
1800V (L-L), 900V (L-G)
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
STP240D07
Zoro #
G1606690
UPC #
782001477929
Country of Origin
Mexico

Dimensions

Length
4.19 in
Depth
2.81 in
Width
2.07 in

Details

CAD Available
Yes
Item
Surge Protection Device
Mounting Style
DIN Rail
Phase
3
Voltage
240V AC
Number of Poles
3
Voltage Protection Rating
1800V (L-L), 900V (L-G)
Number of Wires
4 Wires
Modes of Protection
L-G, L-L
Max. Surge Current Per Mode
150kA
Max. Surge Current per Mode
75 kA
Max. Surge Current per Phase
75 kA
Nominal Discharge Current
20 kA
Short Circuit Current Rating
200kA
Modular
Yes
Filtering
No
Max. Continuing Operating Voltage
275/550V AC
Enclosure NEMA Rating
NEMA 1
IP Rating
IP20
Enclosure Material
Thermoplastic
Wire Gauge
14 to 4 AWG
Includes
Mechanical Indication
Lightning Impulse Current
75 kA
Standards
ANSI/UL 1449 4th Edition, ANSI/IEEE C62.41.1, C62.41.2, C62.45, RoHS Compliant, Type 1
Modular / Nonmodular
Modular
UL SPD Type
Type 1
Min. Operating Temp.
-40 Degrees F
System Connection
Parallel
Color
Gray
Max. Operating Temp.
185 Degrees F
Amps
75 kA
Basic Material
Nonmetallic
Status Indicator
Mechanical Flag
Includes Surge Counter
No
Max Operating Temp
85 °C
Installation Mounting
DIN Rail
Ac Or Dc
AC
Min Operating Temp
-40 °C
Wire Connections
Box
System Configuration
Three Phase Delta
Replacement Plug L2
SP07U275
Protection Modes
L-L
Flammability Rating
UL94 V0
Max Discharge Current Imax 8 20
75kA
Replacement Plug L3
SP07U275
Mcov L-G
275 V
Torque Rating
35.4 lb-in
APPROVALS & STANDARDS
ANSI/UL 1449 4th Edition,; ANSI/IEEE C62.41.1, C62.41.2,
Max Storage Temp
85 °C
MOV Response Time
<25 ns
Housing Material
PET (Polyethelene Terphthalate)
Connection Terminal Type
Box
Frequency
50/60 Hz
Min Storage Temp
-40 °C
Max Discharge Current : Imax (8/20)
75kA
Short Description
SPD - Plugable STP 75 Series 240V L-L VPR 1800V L-L MCOV 550V 75 kA 3-pole
Connection/Terminal Type
Box
Replacement Plug L1
SP07U275
Mcov L-L
550 V
Response Time
<25 ns
Item Description (ERP)
STP T1 75kA 240V DELTA
Wire Type
Solid / Stranded CU
Wiring Range
#4 to #14 AWG

Description

Surge Protection Device, Nonmetallic, Gray, Amps 75 kA, Depth 2.81 in, Enclosure Material Polyethylene Terephthalate, Enclosure NEMA Rating 1
