- Item
- UPS System
- UPS Type
- Standby
- Power Rating
- 350VA
- Mounting
- Desktop/Tower
- Wattage
- 210 W
- Input Voltage
- 120V AC
- Output Voltage
- 110/115/120V AC
- Backup Time (Half/Full Load)
- 7 min/2 min
- Outlet Type
- (3) Surge; (3) UPS/Surge
- Medical Grade
- No
- Number of Outlets
- 6
- Input Current
- 10 A
- Phase
- Single
- Special Features
- Cold Start Operation Supported
- NEMA Plug Configuration
- 5-15P
- Automatic Volts Regulation
- No
- Hz
- 60 Hz
- Ports
- USB (HID enabled)
- Transfer Time
- 2 msec from Battery to AC, 4 msec from AC to Battery
- Green Environmental Attribute
- Product Contributes To Reducing Energy Consumption
- Fax/Modem Line Protection
- Yes
- NEMA Receptacle Configuration
- (6) 5-15R
- VA Rating - UPS Systems
- 350.0 VA
- Display Type
- No Display
- Footnotes
- 4,6
- Includes
- USB Cables
- Standards
- CSA, CSA-C22.2 No. 107.3, FCC Part 15 Class B, NOM, RoHS, UL1778
- Voltage
- 120
- Input Connection
- 6 ft Cord with NEMA 5-15P Plug
- Battery Type
- VRLA
- Housing Material
- ABS
- Housing Color
- Black
- Output Volt Amp Capacity (VA)
- 350
- Output Watt Capacity (Watts)
- 210
- Audible Alarm
- UPS remains silent in battery backup mode; Alarm sounds only to report low-battery, fault, overload and replace-battery conditions
- Half Load Runtime (min.)
- 7 min. (105w)
- Expandable Runtime
- No
- Input Circuit Breakers
- 5A
- Communications Interface
- USB (HID enabled)
- Storage Temperature Range
- +5 to +113 degrees Fahrenheit / -15 to +45 degrees Celsius
- Individually Controllable Load Banks
- No
- Relative Humidity
- 0 to 90%, non-condensing
- Input Phase
- Single-Phase
- Cold Start (Startup in Battery Mode During a Power Failure)
- Cold-start operation supported
- Nominal Output Voltage(s) Supported
- 110V; 115V; 120V
- PowerAlert Software
- For local monitoring via the UPSâ„¢s built-in USB port, download PowerAlert Local software at http://www.tripplite.com/poweralert
- Recommended Electrical Service
- 15A 120V
- WatchDog Compatibility
- Supports Watchdog application, OS and hard-reboot restart options for remote applications
- Battery Access
- Battery access door
- Output AC Waveform (Battery Mode)
- PWM sine wave
- AC Mode Efficiency Rating (100% Load)
- >98%
- Primary Form Factor
- Desktop
- Full Load Runtime (min.)
- 2 min. (210w)
- Installation Form Factors Supported with Included Accessories
- Tower; Ultra-compact desktop; Wallmount
- DC System Voltage (VDC)
- 12
- Low Voltage Transfer to Battery Power (Setpoint)
- 95
- Operating Temperature Range
- +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
- UPS Dataline Suppression
- 1 line TEL/DSL or Ethernet
- EMI / RFI AC Noise Suppression
- Yes
- Nominal Input Voltage(s) Supported
- 120V AC
- Switches
- Switch controls power off/on status
- UPS Certification Details
- UL1778: 2014 5th EDITION; CAN/CSA-C22.2 NO. 107.3:2014 3rd EDITION; FCC CLASS B; FCC Part 68 Approved (#5WSWP01B005); Industry Canada Approved (#3449A-005, REN0.1B); RETIE (Colombia)
- Rated input current (Maximum Load)
- 5A
- High Voltage Transfer to Battery Power (Setpoint)
- 145
- Output Voltage Regulation (Battery Mode)
- 120V (±10%)
- AC Mode BTU / Hr. (Full Load)
- 13.1
- LED Indicators
- 1 Status LED reports operating mode and fault status
- Battery Replacement Description
- Replaceable internal batteries (see manual)
- UPS AC Suppression Joule Rating
- 316
- Output Voltage Regulation (Line Mode)
- 120V (±20%)
- Battery Recharge Rate (Included Batteries)
- 6.5 hours (10% to 90%)
- UPS Certifications
- Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B (EMI)
- High Availability UPS Features
- Battery Independent Restart
- Communications Cable
- USB interface cable included
- Typical Battery Recharge Time
- 4 Hour
- Modem (RJ-11)
- Yes
- Software Included
- PowerAlert Software
- Status Indicators
- Line Power, Battery Power Status
- Package Contents
- Internet Office 350VA UPS, UPS System, USB communications cable, Instruction manual with warranty information
- Dataline Protection
- RJ-11
- Battery Chemistry
- Valve Regulated Lead Acid
- Load Capacity
- 350 VA/180 W
- Form Factor
- Ultra-compact Desk-mount
- Assembly Required
- No
- Additional Information
- Line mode BTU/hr. (Max.): 15.7, Battery mode BTU/hr. (Max.): 53.2, Cold Start: Inverter can be cold started to enable temporary AC output during a power failure, Switches: Combination power off / on / self-test push button switch
- Hot Swappable
- Yes
- Battery Life
- 6 Year
- Waveform Type
- Pulse-width Modulated Sine Wave
- Protection Type
- Brownout, Black Out
- Maximum Operating Temperature
- 122°F (50°C)
- Alarm
- On Battery, Self-test Operation
- Sound Emission
- 40 dB
- Surge Energy Rating
- 380 J
- USB
- Yes
- Product Certifications
- RETIE (Colombia); CSA (Canada); CAN/CSA-C22.2 No. 107.3 (Canada); NOM (Mexico); UL 1778
- Package Includes
- INTERNET350U 350VA 210W 120V Standby UPS with 6 Outlets;USB cable;Owner's manual
- Output Capacity (VA)
- 350
- Output Capacity (Watts)
- 210
- Product Compliance
- FCC Part 15 Class B (USA)
- UPS Applications
- Computer/Peripherals; Retail/Point of Sale; Hospitality
- Data Line Protection
- Includes Data Line Surge Protection
- Run Time - Full Load
- 2 min
- Input Current - Maximum
- 5 A
- Surge Suppression Rating
- 316 J
- Manufacturer Warranty
- 3 yr Limited
- Includes Battery
- Battery Included
- Power Rating - Apparent
- 350 VA
- Operating Temperature - Minimum
- 32 Degrees F
- Automatic Voltage Regulation
- No Automatic Voltage Regulation
- Operating Temperature - Maximum
- 104 Degrees F
- Number of Outlets - UPS
- 3
- Transfer Time - Minimum
- 6 msec
- Number of Outlets - Surge Only
- 3
- Visible Indicator Light Conditions
- Fault
- Output Ports Included
- USB
- Power Rating - Real
- 180 W
- Receptacle Configuration
- 5-15R
- External Battery Compatible
- Not External Battery Pack Compatible
- Plug Configuration
- 5-15P
- Transfer Time - Maximum
- 10 msec
- Frequency
- 50/60 Hz
- Audible Alarm Conditions
- Low Battery, Overload, Replace Battery
- Battery Recharge Time
- 6.5 hr
