Mersen Surge Protection Device, PV Phase, 600VDC STP600PVM

Surge Protection Device, PV Phase, 600VDC (Discontinued)

  • Mfr # STP600PVM
  • Zoro # G2213696
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
STP600PVM
Zoro #
G2213696
UPC #
-
Country of Origin
Mexico

Dimensions

Width
1.4 in
Length
3.89 in
Depth
2.8 in
Length (Straight Wireway)
3.89 in

Details

Item
Surge Protection Device
Phase
Photovoltaic
Voltage
600V DC
Max. Continuing Operating Voltage
720 V DC
Voltage Protection Rating
2000V (DC- - G), 2000V (DC+ - DC-), 2000V
Nominal Discharge Current
20 kA
Modes of Protection
(DC+)-(DC-), (DC+/-)-G
Filtering / Nonfiltering
Nonfiltering
Modular / Nonmodular
Modular
Max. Surge Current Per Phase
50kA
Short Circuit Current Rating
200kA
IP Rating
20
Number of Wires
3 Wires
Standards
UL1449 3rd Edition/ IEC 61643
Includes
Microswitch
Mounting Style
DIN-Rail/Pluggable
Number of Poles
2
Wire Gauge
14 to 6 AWG
Enclosure Material
Polyethylene Terephthalate
Max. Surge Current Per Mode
50kA
Max. Surge Current per Mode
50kA
Max. Surge Current per Phase
50 kA
Filtering
No
Modular
Yes
System Connection
Parallel
Basic Material
Nonmetallic
Includes Surge Counter
No

Description

Surge Protection Device, Nonmetallic, Depth 2.8 in, Enclosure Material Polyethylene Terephthalate
