Shop All Vibrators
Millennium

Silent Turbine Vibrator, 270 lb.

product price: $281.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Vibrator Type Turbine
  • Force Rating 270 lb
  • CFM @ 80 PSI 8.5
  • Speed @ 60 psi 5,500 vpm
  • Speed @ 80 psi 7,200 vpm
See all product information

Product Information

Dimensions

Overall Length 4.49 in
Overall Width 3.39 in
Overall Height 3.19 in
Mount Hole Size 10
Inlet Connection Size 1/4 in
Outlet Connection Size 3/8 in
Mount Hole Center-to-Center Length 89 mm

Details

Vibrator Type Turbine
Item Pneumatic Vibrator
Force Rating 270 lb
CFM @ 80 PSI 8.5
Speed @ 60 psi 5,500 vpm
Speed @ 80 psi 7,200 vpm
dB @ 60 psi 71
dB @ 80 psi 71
Bin Weight Capacity 2,700 lb
Inlet Port 1/4 in NPT
Outlet Port 3/8 in NPT
Mounting Plate No
CFM @ 60 psi 7.5
Mounting Channel Iron and Mounting Plate Recommended
Housing Material Aluminum
Max. Temp. 200 Degrees F
Max. Pressure 80 max
Duty Continuous
Muffler Optional
Application Beverage, Chemical, Food, Pharmaceutical Industries
Standards OSHA
Maximum Force 270 lbf
Vibration Speeds @ PSI 7,000 vpm @ 60 psi, 7,200 vpm @ 80 psi
Outlet Connection Type NPT
Force @ 80 psi 270 lbf
Maximum Vibration Speed 7,200 vpm
Air Flow Rate 7.5 cfm @ 60 psi, 8.5 cfm @ 80 psi
Vibration Speed @ 60 psi 5,500 vpm
Inlet Connection Type NPT
Series MLT
Mount Plate Required No
Duty Cycle Continuous
Maximum Operating Temperature 250 Degrees F
Weight 2 lb
Sound Level 68 dBA
Force @ PSI 160 lbf @ 60 psi, 270 lbf @ 80 psi
Vibration Speed @ 80 psi 7,200 vpm
Mount Type Channel Iron and Mounting Plate Recommended
Maximum Bin Weight Capacity 2,700 lb
Pneumatic Vibrator Type Turbine
Force @ 60 psi 160 lbf

Description

Pneumatic Vibrator, Housing Material Aluminum, Outlet Connection Size 3/8 in, Outlet Connection Type NPT, Air Flow Rate 7.5 cfm @ 60 psi, 8.5 cfm @ 80 psi, Maximum Force 270 lbf, Inlet Connection Size 1/4 in, Inlet Connection Type NPT, Maximum Vibration Speed 7,200 vpm, Maximum Bin Weight Capacity 2,700 lb, Overall Height 3.19 in, Overall Length 4.49 in, Overall Width 3.39 in, Sound Level 68 dBA, Duty Cycle Continuous, Pneumatic Vibrator Type Turbine
