Shop MILWAUKEE VALVE

Ball Valve, 1/2" Tube Size, FNPT x FNPT

  • Mfr # 35FSSN0LL-012

  • Zoro # G7238408

product price:  $125.99
/ea
Free Shipping & Returns

Key Features

Ball Material
316 stainless steel
Body Style
2-Way
Ball Port Style
Full Port
Valve Ways
2-Way
Valve Structure
Three-Piece
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
35FSSN0LL-012
Zoro #
G7238408
UPC #
697988659353
Country of Origin
China

Dimensions

Pipe Size
1/2 in
Overall Length
2.74 in
Handle Height
2.62 in
Connection Size - Side 1
1/2 in
Connection Size - Side 2
1/2 in
Nominal Valve Size
1/2 in
Handle Length
4.21 in

Details

Ball Material
316 stainless steel
Body Style
2-Way
Ball Port Style
Full Port
Valve Ways
2-Way
Valve Structure
Three-Piece
For Media
Combustible Gases, Water
Connection Type
FNPT x FNPT
Item
Ball Valve
Body Material
Stainless Steel
Temp. Range
-20 Degrees to 450 Degrees F
Stem Material
316 Stainless Steel
Hose I.D.
1 in
Stem Type
Blowout Resistant
Handle Type
Lever
Handle Material
Stainless Steel
Standards
API, ASME, ASTM, ISO 5211
Seat Material
Polymer
Max. Pressure
2,000 PSI CWP
Features
Multiple Configurations
Compliance
ASME B16.34 Class 800, NACE MR0175
Seal Material
Graphite
Special Features
Actuator Compatible
Color - Valve Handle
Blue
Vented Ball Valve
Vented
Operating Temperature - Maximum
450 Degrees F
Vacuum Service Rating
-29.92 in Hg
Included Mounting
Actuator Mounting Pad
Connection Gender - Side 1
Female
Connection Gender - Side 2
Female
Maximum Pressure - Steam
150 psi
Connection Type - Side 1
NPT
Coefficient of Volume (Cv)
15
3-A Standard Compliance
Not Rated
Cleaned and Bagged
Valve Cleaned and Bagged
Handle - Locking
Locking
Connection Type - Side 2
NPT
Operating Temperature - Minimum
20 Degrees F
Maximum Pressure - Combustible Gas
Not Rated
Valve Series
35
Valve Construction
Three-Piece
Maximum Pressure - Operating
2,000 psi
Valve Body Style
Straight

Description

Manual Two-Way Ball Valve, Body Material Stainless Steel, For Media Combustible Gases, Water, Valve Construction Three-Piece, Nominal Valve Size 1/2 in, Valve Body Style Straight, 3-A Standard Compliance Not Rated, Average Surface Roughness (Ra) Not Applicable, Maximum Pressure - Operating 2,000 psi, Maximum Pressure - Steam 150 psi, Maximum Pressure - Combustible Gas Not Rated, Vacuum Service Rating -29.92 in Hg, Ball Material Stainless Steel, Ball Port Style Full Port, Handle - Locking Locking

Restrictions

This is a restricted item in the USA. It cannot be used for potable water applications.
