Disc Valve, 1 Pc, 2 In, Bronze, FNPT

  • Mfr # BB2-100 2

  • Zoro # G0511454


product price: $90.59
/ea
Free Shipping & Returns

Key Features

Body Material
Bronze
Pipe Size
2 in
Max. Water Pressure
175 psi
Handle Type
Lever
Temp. Range
30 to 275 Degrees F
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
BB2-100 2
Zoro #
G0511454
UPC #
697988579392
Country of Origin
United States

Dimensions

Pipe Size
2 in
Handle Length
5 in
Nominal Valve Size
2 in

Details

Item
Butterfly Disc Valve
Body Material
Bronze
Max. Water Pressure
175 psi
Handle Type
Lever
Temp. Range
30 to 275 Degrees F
Disc Material
304 Stainless Steel
Liner Material
FKM
Standards
AGA, cCSAus, cULus, UL Listed
Seal Material
FKM
Handle Material
Zinc-Plated Steel
Includes Disc Position Indicator
Disc Position Indicator Included
Operating Temperature - Minimum
30 Degrees F
Manufacturer Warranty
1 yr
Operating Temperature - Maximum
275 Degrees F
Stem Material
303 Stainless Steel
Connection Type
NPT
Vacuum Service Rating
-29 in Hg
For Media
Gas, Oil, Water
3-A Standard Compliance
Not Rated
Maximum Pressure - Operating
175 psi
Coefficient of Volume (Cv)
180
Valve Series
BB2

Description

Butterfly Disc Valve, Body Material Bronze, Max. Water Pressure 175 psi, Pipe Size 2 in, Temp. Range 30 to 275 Degrees F, Liner Material FKM, Disc Material 304 Stainless Steel, Handle Type Lever, Standards AGA, cCSAus, cULus, UL Listed

Restrictions

This is a restricted item in the USA. It cannot be used for potable water applications.
