Vertical Profile Projectors, 12.4" Size

product price: $12,683.99
/ea
Item requires special delivery charges. A $150.00 per item surcharge will be applied.
Free 30-Day Returns

Key Features

  • Accuracy +/-0.1% Or Less (Contour), +/-0.15% Or Less (Surface)
  • Table Size (In.) 9-15/16 x 9-15/16
  • Power Supply Corded
  • Magnification 10x
  • Focusing Travel 3.58 in
See all product information

Product Information

Dimensions

Table Size (In.) 9-15/16 x 9-15/16
Size 12.4 in
Screen Size 12.4 in
Maximum Workpiece Height 3.58 in
Table Size 9 15/16 in x 9 15/16 in

Details

Item Optical Comparator
Accuracy +/-0.1% Or Less (Contour), +/-0.15% Or Less (Surface)
Power Supply Corded
Magnification 10x
Focusing Travel 3.58 in
Capacity (Lb.) Max. 100
Reading Linear Scale
Table Travel X Axis=4 in, Y Axis=4 in
Illumination 24V, 150 W Halogen
Includes Projection Lens Set, Masking Shield, Power Cord, Halogen Bulb, Fuse, Grounding Wire, Hex Wrench, Vinyl Cover
Resolution 0.0001 in/0.001mm
Protractor Screen 12.4 in
Projector Series Mitutoyo PJ-A3000
Image Type Inverted Image
Reference Line Style Cross Hair Line
Measuring Unit Linear Scale
Effective Table Working Area 7 1/4 in x 3 1/4 in
X-Axis Table Travel 4 in
Screen Material Fine Ground Glass
Contour Illumination 24V, 150W Halogen Bulb
Adjustable Brightness Yes
Magnification - Included Lens 10X
Optical System Orientation Vertical
Y-Axis Vertical Focus Travel 3.58 in
Surface Illumination 24V, 150W Halogen Bulb

Description

Optical Comparator, Resolution 0.0001 in/0.001mm, Accuracy +/-0.1 Percent Or Less (Contour), +/-0.15 Percent Or Less (Surface), Contour Illumination 24V, 150W Halogen Bulb, Effective Table Working Area 7 1/4 in x 3 1/4 in, Image Type Inverted Image, Magnification - Included Lens 10X, Measuring Unit Linear Scale, Optical System Orientation Vertical, Projector Series Mitutoyo PJ-A3000, Screen Size 12.4 in, Surface Illumination 24V, 150W Halogen Bulb, Table Size 9 15/16 in x 9 15/16 in
