  9. Flow Meter, 6 in. Fitting Size, Aluminum
Modmag Flow Meter, 6 in. Fitting Size, Aluminum 108-9864 - main

Flow Meter, 6 in. Fitting Size, Aluminum

  • Mfr # 108-9864

  • Zoro # G4309210

product price: $3,399.99
/ea
Free Shipping & Returns

Key Features

Housing Material
Steel
Type
Electromagnetic
For Pipe Size
6 in
Connection Size
6 in
Flow Material
Chemicals, High Viscosity, Lubricants, Oil, Thick Fluids
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
108-9864
Zoro #
G4309210
UPC #
-
Country of Origin
Czechia

Dimensions

For Pipe Size
6 in
Connection Size
6 in
Length (In.)
15 13/16 in
Pipe Size
6"
Fitting Size (In.)
6
Overall Length
15.8 in
Overall Height
11.1 in
Overall Width
7.1 in

Details

Item
Electronic Flowmeter
Housing Material
Steel
Type
Electromagnetic
Flow Material
Chemicals, High Viscosity, Lubricants, Oil, Thick Fluids
Connection Type
Flange
Wetted Materials
Hard Rubber Liner, Electrode
Flow Range
7.85 to 3141 gpm
Fluid Temp. Range
0 Degrees to 178 Degrees F
Sensor Type
Electromagnetic
Fitting Type
150 lb. Flange
Fluid Temp. Range (Deg. C)
0 to 80
Repeatability
0.10%
Flow Range (GPM)
7.85 to 3141
Fluid Temp. Range (Deg. F)
0 to 178
Includes
Grounding Rings
Standards
AWW C-700 NSF/ANSI 61&372
Accuracy (%)
+/-0.25
Power Requirement
85-265V AC
Display Type
Digital
Ambient Temperature
-40 Degrees to 140 Degrees F
Display Units
BPM, F3H, F3M, F3S, Gallons Per Hour, Gallons Per Minute, Gallons Per Second, IGH, IGM, IGS, LbM, Liter Per Hour, Liter Per Minute, Liter Per Second, M3H, M3S, Million Gallons per Day, OPM
Special Features
Measures Almost Any Electrical Conductive Fluid
Seal Material
EPDM
Shaft Material
Stainless Steel
Output Type
Standard Frequency Pulse
Includes Totalizer
Yes
Flowmeter Type
Electromagnetic
Viscosity - Maximum
32.6 SUS
Media Temperature - Minimum
32 Degrees F
Product Type
Electromagnetic Flow Meter
Voltage - Maximum
240V AC
Flow Rate - Maximum
3,361 gpm
Includes Flow Rate Adjustment Knob
No
Compatible Flow Material
Water
Accuracy
+/-1.5%
Includes Pressure Gauge
No
Operating Pressure - Maximum
150 psi
Media Temperature - Maximum
80 Degrees F
Wetted Material
Bronze, Noryl, Nylon, Polyethylene, Styrene Acrylonitrile
Flow Rate - Minimum
8.4 gpm
Unit Of Measure
Gallons
Mounting Orientation
Universal

Description

Electronic Flowmeter, Product Type Electromagnetic Flow Meter, Flowmeter Type Electromagnetic, Accuracy +/-1.5 Percent, Connection Size 6 in, Connection Type Flange, Compatible Flow Material Water, Media Temperature - Maximum 80 Degrees F, Media Temperature - Minimum 32 Degrees F, Viscosity - Maximum 32.6 SUS, Voltage - Maximum 240V AC, Housing Material Steel, Rotor Material Not Applicable, O-Ring Material Not Applicable, Seal Material EPDM, Shaft Material Stainless Steel

Restrictions

Hazardous material
