  9. 1.25Wb Single St Assy 4Ckt Embpkg Red
This item is Discontinued.
Molex 1.25Wb Single St Assy 4Ckt Embpkg Red 5055680472

1.25Wb Single St Assy 4Ckt Embpkg Red (Discontinued)

  • Mfr # 5055680472
  • Zoro # G305910650
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
5055680472
Zoro #
G305910650
UPC #
-
Country of Origin
Malaysia

Details

Number of Rows
1
Application
Signal, Wire-to-Board
Color - Resin
Red
Shrouded
Fully
Voltage - Maximum
50V AC (RMS)/DC
Durability (mating cycles max)
30
Material - Resin
Polyamide
Plating min - Mating
1.000µm
Circuits (Loaded)
4
Orientation
Vertical
Glow-Wire Capable
No
Termination Interface Style
Surface Mount
First Mate / Last Break
No
Keying to Mating Part
Yes
Polarized to Mating Part
Yes
Material - Metal
Brass
Material - Plating Mating
Tin-Bismuth
Product Name
Micro-Lock Plus
Current - Maximum per Contact
1.5A
PCB Retention
Yes
Stackable
No
Lock to Mating Part
Yes
Material - Plating Termination
Tin-Bismuth
Component Type
PCB Header
Robotic Placement
Vacuum Pick-Up Tape
Series
505568
PCB Locator
No
Breakaway
No
Guide to Mating Part
No
Polarized to PCB
Yes
UL
E29179
Pitch - Mating Interface
1.25mm
Temperature Range - Operating
-40° to +105°C
