  6. Board Connector, 10 Contact(S), 1 Row(S), Male, Straight, 0.1 Inch Pitch, Solder Terminal, Black
Molex Board Connector, 10 Contact(S), 1 Row(S), Male, Straight, 0.1 Inch Pitch, Solder Terminal, Black 901200770 - main

Board Connector, 10 Contact(S), 1 Row(S), Male, Straight, 0.1 Inch Pitch, Solder Terminal, Black

  • Mfr # 901200770

  • Zoro # G505891094

product price:  $1.35
/ea
Sold in multiples of 57 for $76.95

Key Features

Application
Signal, Wire-to-Board
Series
90120
Circuits (Loaded)
10
Max-Cycle
1
Breakaway
Yes
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
901200770
Zoro #
G505891094
UPC #
-
Country of Origin
Singapore

Dimensions

PC Tail Length
2.90mm
PCB Thickness - Recommended
1.60mm

Details

Application
Signal, Wire-to-Board
Series
90120
Circuits (Loaded)
10
Max-Cycle
1
Breakaway
Yes
Keying to Mating Part
None
PCB Retention
None
PCB Locator
No
Component Type
PCB Header
Material - Plating Termination
Nickel
Flammability
94V-0
Current - Maximum per Contact
3.0A
Stackable
No
Number of Rows
1
Product Name
C-Grid III
Temperature Range - Operating
-55° to +125°C
Shrouded
No
Lock to Mating Part
None
Orientation
Vertical
First Mate / Last Break
No
Polarized to PCB
No
Guide to Mating Part
No
Voltage - Maximum
350V AC/DC
Pitch - Mating Interface
2.54mm
CSA
LR19980
Material - Metal
Brass
Glow-Wire Capable
No
Termination Interface Style
Through Hole
Plating min - Mating
0.381µm
Max-Temp
260
Durability (mating cycles max)
200
Material - Plating Mating
Gold
Material - Resin
Polyester
Max-Duration
5
Polarized to Mating Part
No
UL
E29179
Color - Resin
Black

Description

Board Connector, 10 Contact(S), 1 Row(S), Male, Straight, 0.1 Inch Pitch, Solder Terminal, Black Insulator, Receptacle
