  11. Board Connector, 20 Contact(S), 2 Row(S), Male, Right Angle, 0.079 Inch Pitch, Solder Terminal,
Molex Board Connector, 20 Contact(S), 2 Row(S), Male, Right Angle, 0.079 Inch Pitch, Solder Terminal, 878332020 - main

Board Connector, 20 Contact(S), 2 Row(S), Male, Right Angle, 0.079 Inch Pitch, Solder Terminal,

  • Mfr # 878332020

  • Zoro # G105891050

product price: $2.29
/ea
Sold in multiples of 46 for $105.34

Key Features

Max. Voltage
125V
Max. Temp.
265°C
Application
Signal, Wire-to-Board
Series
87833
Standards
CSA Certified; UL E29179
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
878332020
Zoro #
G105891050
UPC #
-
Country of Origin
Malaysia

Dimensions

Contact Plating Thickness
0.381 µm
PC Tail Length
2.16mm
PCB Thickness - Recommended
1.60mm

Details

Max. Voltage
125V
Max. Temp.
265°C
Application
Signal, Wire-to-Board
Series
87833
Standards
CSA Certified; UL E29179
Features
Surface Mount Compatible
Terminal Type
Through Hole
Hole Center to Center
2 mm
Color
Black
Material
Nylon
Number of Contacts
20
Number of Rows
2
Terminal Finish
Tin Plated
Current Rating
2 A
Flammability Rating
UL 94V-0
Contact Finish
Gold Plated
CSA
LR19980
Temperature Range - Operating
-55° to +105°C
Material - Metal
Phosphor Bronze
Shrouded
Fully
Guide to Mating Part
No
PCB Retention
None
Material - Plating Termination
Tin
Max-Duration
11
Pitch - Mating Interface
2.00mm
Current - Maximum per Contact
2.0A
First Mate / Last Break
No
Max-Temp
265
Keying to Mating Part
None
UL
E29179
Polarized to PCB
No
Lock to Mating Part
Yes
Flammability
94V-0
PCB Locator
No
Material - Resin
Nylon
Circuits (Loaded)
20
Product Name
Milli-Grid
Stackable
No
Durability (mating cycles max)
100
Breakaway
No
Plating min - Mating
0.381µm
Component Type
PCB Header
Max-Cycle
1
Glow-Wire Capable
No
Orientation
Right Angle
Material - Plating Mating
Gold

Description

Board Connector, 20 Contact(S), 2 Row(S), Male, Right Angle, 0.079 Inch Pitch, Solder Terminal, Locking, Black Insulator, Receptacle
