  11. Board Connector, 4 Contact(S), 1 Row(S), Female, Right Angle, 0.1 Inch Pitch, Solder Terminal,
Molex Board Connector, 4 Contact(S), 1 Row(S), Female, Right Angle, 0.1 Inch Pitch, Solder Terminal, 38001334 - main

Board Connector, 4 Contact(S), 1 Row(S), Female, Right Angle, 0.1 Inch Pitch, Solder Terminal,

  • Mfr # 38001334

  • Zoro # G505893401

product price: $0.88
/ea
Sold in multiples of 100 for $88.00

Key Features

Max. Temp.
235°C
Max. Voltage
500V
Application
Board-to-Board, Signal
Series
4455
Standards
CSA Certified; UL E29179
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
38001334
Zoro #
G505893401
UPC #
-
Country of Origin
Mexico

Dimensions

Contact Plating Thickness
1.016 µm
PCB Thickness - Recommended
1.60mm
PC Tail Length
3.30mm

Details

Max. Temp.
235°C
Max. Voltage
500V
Application
Board-to-Board, Signal
Series
4455
Standards
CSA Certified; UL E29179
Material
Nylon
Color
Natural
Hole Center to Center
2.54 mm
Terminal Type
Through Hole
Contact Finish
Tin Plated
Terminal Finish
Tin Plated
Flammability Rating
UL 94V-0
Number of Contacts
4
Current Rating
2.5 A
Number of Rows
1
PCB Retention
Yes
Max-Duration
5
Color - Resin
Natural (White)
Keying to Mating Part
None
Glow-Wire Capable
No
Material - Plating Mating
Tin
UL
E29179
Grounding to PCB
No
Lock to Mating Part
No
Polarized to PCB
Yes
Max-Temp
235
Material - Metal
Phosphor Bronze
Temperature Range - Operating
See Product Specification
Guide to Mating Part
No
Current - Maximum per Contact
2.5A
Flammability
94V-0
Material - Resin
Nylon
Circuits (Loaded)
4
PCB Locator
No
Pitch - Mating Interface
2.54mm
CSA
LR19980
Orientation
Right Angle
Material - Plating Termination
Tin
Product Name
KK 254
Plating min - Mating
1.016µm
Component Type
PCB Receptacle

Description

Board Connector, 4 Contact(S), 1 Row(S), Female, Right Angle, 0.1 Inch Pitch, Solder Terminal, White Insulator, Plug
