  11. Board Connector, 7 Contact(S), 1 Row(S), Male, Straight, 0.059 Inch Pitch, Surface Mount Terminal,
Molex Board Connector, 7 Contact(S), 1 Row(S), Male, Straight, 0.059 Inch Pitch, Surface Mount Terminal, 874370763 - main

Board Connector, 7 Contact(S), 1 Row(S), Male, Straight, 0.059 Inch Pitch, Surface Mount Terminal,

  • Mfr # 874370763

  • Zoro # G005890849

product price: $1.25
/ea
Sold in multiples of 900 for $1,125.00

Key Features

Max. Temp.
105°C
Max. Voltage
250V AC/DC
Application
Signal, Wire-to-Board
Series
87437
Standards
CSA Certified; UL E29179
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
874370763
Zoro #
G005890849
UPC #
-
Country of Origin
Malaysia

Dimensions

Contact Plating Thickness
2.54 µm

Details

Max. Temp.
105°C
Max. Voltage
250V AC/DC
Application
Signal, Wire-to-Board
Series
87437
Standards
CSA Certified; UL E29179
Color
Black
Terminal Type
Surface Mount
Material
Nylon
Hole Center to Center
1.5 mm
Contact Finish
Tin Plated
Flammability Rating
UL 94V-0
Number of Rows
1
Terminal Finish
Tin Plated
Current Rating
2.5 A
Number of Contacts
7
Flammability
94V-0
Material - Plating Mating
Tin
Guide to Mating Part
No
Voltage - Maximum
250V AC (RMS)/DC
Orientation
Vertical
Robotic Placement
Pick and Place Cap
CSA
LR19980
PCB Locator
No
PCB Retention
None
Lock to Mating Part
Yes
Glow-Wire Capable
No
UL
E29179
Material - Resin
Nylon
Component Type
PCB Header
Material - Plating Termination
Tin
Stackable
No
Material - Metal
Brass
Shrouded
Fully
Circuits (Loaded)
7
Temperature Range - Operating
-55° to +105°C
First Mate / Last Break
No
Current - Maximum per Contact
2.5A
Polarized to Mating Part
Yes
Plating min - Mating
2.540µm
Breakaway
No
Durability (mating cycles max)
10
Product Name
Pico-SPOX
Pitch - Mating Interface
1.50mm
Keying to Mating Part
None
Polarized to PCB
No

Description

Board Connector, 7 Contact(S), 1 Row(S), Male, Straight, 0.059 Inch Pitch, Surface Mount Terminal, Locking, Black Insulator, Plug
