Molex Board To Board & Mezzanine Connectors Slimgrid Shrd Hdr Ra Smt 0.05Aulf 8Ckt 2011730008 - main

Board To Board & Mezzanine Connectors Slimgrid Shrd Hdr Ra Smt 0.05Aulf 8Ckt

  • Mfr # 2011730008

  • Zoro # G305820225

product price:  $1.39
/ea
Sold in multiples of 60 for $83.40

Key Features

Max. Temp.
260°C
Max. Voltage
125V AC
Application
Board-to-Board, Signal
Series
201173
Standards
CSA Certified; UL E29179
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
2011730008
Zoro #
G305820225
UPC #
-
Country of Origin
Singapore

Dimensions

Contact Plating Thickness
0.051 µm

Details

Max. Temp.
260°C
Max. Voltage
125V AC
Application
Board-to-Board, Signal
Series
201173
Standards
CSA Certified; UL E29179
Terminal Type
Surface Mount
Material
Liquid Crystal Polymer
Hole Center to Center
1.27 mm
Color
Black
Current Rating
1.4 A
Flammability Rating
UL 94V-0
Number of Contacts
8
Contact Finish
Gold Plated
Number of Rows
2
Terminal Finish
Matte Tin Plated
Max-Temp
260
Material - Metal
Copper Alloy
UL
E29179
PCB Retention
None
Keying to Mating Part
None
Max-Duration
10
Lock to Mating Part
Yes
CSA
LR19980
Shrouded
Fully
First Mate / Last Break
No
Material - Resin
Liquid Crystal Polymer
Plating min - Mating
0.051µm
Material - Plating Mating
Gold
Current - Maximum per Contact
1.4A
Breakaway
No
Polarized to PCB
No
Product Name
Slim-Grid
Orientation
Right Angle
Material - Plating Termination
Matte Tin
Glow-Wire Capable
No
Circuits (Loaded)
8
Flammability
94V-0
Pitch - Mating Interface
1.27mm
Durability (mating cycles max)
500
Temperature Range - Operating
-55° to +105°C
Polarized to Mating Part
Yes
Max-Cycle
1
Guide to Mating Part
Yes
Component Type
PCB Header
PCB Locator
No
