  9. Headers & Wire Housings C-Grid Pcb Conn Sr V Conn Sr Vt Au-E 6Ckt
Molex Headers & Wire Housings C-Grid Pcb Conn Sr V Conn Sr Vt Au-E 6Ckt 901471206 - main

Headers & Wire Housings C-Grid Pcb Conn Sr V Conn Sr Vt Au-E 6Ckt

  • Mfr # 901471206

  • Zoro # G105911598

product price: $2.15
/ea
Sold in multiples of 72 for $154.80

Key Features

Number of Rows
1
Series
90147
Application
Board-to-Board, Signal
Circuits (Loaded)
6
Material - Plating Termination
Tin
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
901471206
Zoro #
G105911598
UPC #
-
Country of Origin
Indonesia

Dimensions

PCB Thickness - Recommended
1.60mm
PC Tail Length
2.90mm

Details

Number of Rows
1
Series
90147
Application
Board-to-Board, Signal
Circuits (Loaded)
6
Material - Plating Termination
Tin
Material - Plating Mating
Gold
Max-Temp
230
Material - Resin
Polyester
PCB Locator
No
Plating min - Mating
0.381µm
Product Name
C-Grid III
Max-Duration
5
Voltage - Maximum
350V
Flammability
94V-0
CSA
LR19980
Pitch - Mating Interface
2.54mm
Orientation
Vertical
Glow-Wire Capable
No
Keying to Mating Part
None
Termination Interface Style
Through Hole
Durability (mating cycles max)
100
Polarized to PCB
No
Current - Maximum per Contact
3.0A
Max-Cycle
1
Color - Resin
Black
Lock to Mating Part
No
Guide to Mating Part
No
Grounding to PCB
No
Component Type
PCB Receptacle
PCB Retention
Yes
Temperature Range - Operating
-55° to +125°C
UL
E29179
Material - Metal
Phosphor Bronze
