  9. Headers & Wire Housings C-Grid Pcb Conn Sr V Conn Sr Vt Au-E 8Ckt
Molex Headers & Wire Housings C-Grid Pcb Conn Sr V Conn Sr Vt Au-E 8Ckt 901471208 - main

Headers & Wire Housings C-Grid Pcb Conn Sr V Conn Sr Vt Au-E 8Ckt

  • Mfr # 901471208

  • Zoro # G505911570

product price: $3.35
/ea
Sold in multiples of 30 for $100.50

Key Features

Number of Rows
1
Series
90147
Application
Board-to-Board, Signal
CSA
LR19980
Material - Plating Termination
Tin
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
901471208
Zoro #
G505911570
UPC #
-
Country of Origin
Indonesia

Dimensions

PC Tail Length
2.90mm
PCB Thickness - Recommended
1.60mm

Details

Number of Rows
1
Series
90147
Application
Board-to-Board, Signal
CSA
LR19980
Material - Plating Termination
Tin
Lock to Mating Part
No
Plating min - Mating
0.381µm
Durability (mating cycles max)
100
Temperature Range - Operating
-55° to +125°C
Color - Resin
Black
Keying to Mating Part
None
Current - Maximum per Contact
3.0A
Material - Plating Mating
Gold
Flammability
94V-0
UL
E29179
Grounding to PCB
No
Circuits (Loaded)
8
PCB Retention
Yes
Material - Metal
Phosphor Bronze
Voltage - Maximum
350V
Component Type
PCB Receptacle
Pitch - Mating Interface
2.54mm
Orientation
Vertical
Product Name
C-Grid III
Material - Resin
Polyester
Polarized to PCB
No
Termination Interface Style
Through Hole
Guide to Mating Part
No
PCB Locator
No
Glow-Wire Capable
No
