Micro-Fit Plus Sr Ra Hdr Assy 30Au 1X5

  • Mfr # 2157603005

  • Zoro # G105909922

product price:
$
3.25
/ea
Sold in multiples of 35 for $113.75

Key Features

Number of Rows
1
Series
215760
Application
Power, Wire-to-Board
Polarized to Mating Part
Yes
Lock to Mating Part
Yes
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
2157603005
Zoro #
G105909922
UPC #
-
Country of Origin
China
Number of Rows
1
Series
215760
Application
Power, Wire-to-Board
Polarized to Mating Part
Yes
Lock to Mating Part
Yes
Pitch - Mating Interface
3.00mm
UL
E29179
Material - Plating Termination
Matte Tin
PCB Retention
Yes
Material - Plating Mating
Gold
Material - Metal
High Copper Alloy
Voltage - Maximum
600V AC (RMS)/DC
Plating min - Mating
0.762µm
Shrouded
Yes
Orientation
Right Angle
Termination Interface Style
Through Hole
Product Name
Micro-Fit+
Breakaway
No
Material - Resin
Liquid Crystal Polymer
Current - Maximum per Contact
12.5A
Polarized to PCB
Yes
CSA
LR19980
Durability (mating cycles max)
200
Component Type
PCB Header
Keying to Mating Part
Yes
First Mate / Last Break
No
Circuits (Loaded)
5
Temperature Range - Operating
-40° to +105°C
Flammability
94V-0
Color - Resin
Black
Glow-Wire Capable
Yes
