Shop MOLEX

Rectangular Power Connector, 18 Contact(S), Female, Solder Terminal, Receptacle

  • Mfr # 444751821

  • Zoro # G505910474

product price:  $6.79
/ea
Sold in multiples of 15 for $101.85

Key Features

Number of Rows
2
Series
44475
Application
Board-to-Board, Power, Wire-to-Board
Plating min - Mating
2.540µm
Circuits (Loaded)
18
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
444751821
Zoro #
G505910474
UPC #
-
Country of Origin
Mexico

Dimensions

PCB Thickness - Recommended
1.60mm

Details

Number of Rows
2
Series
44475
Application
Board-to-Board, Power, Wire-to-Board
Plating min - Mating
2.540µm
Circuits (Loaded)
18
PCB Locator
Yes
Max-Temp
240
PCB Retention
Yes
Orientation
Vertical
Temperature Range - Operating
-40° to +105°C
Durability (mating cycles max)
30
Max-Duration
5
Product Name
Mini-Fit HCS
CSA
LR19980
Termination Interface Style
Through Hole
Current - Maximum per Contact
11.0A
Flammability
94V-0
Pitch - Mating Interface
4.20mm
Material - Resin
Nylon
Polarized to PCB
Yes
Glow-Wire Capable
No
UL
E29179
Material - Metal
Copper
Color - Resin
Natural (White)
Material - Plating Mating
Tin
Max-Cycle
1
Voltage - Maximum
600V
Material - Plating Termination
Tin
Component Type
PCB Receptacle
