  11. Sl Positive Lock R-S 8Ckt 300Mm Sn
Molex Sl Positive Lock R-S 8Ckt 300Mm Sn 2162711083 - main

Sl Positive Lock R-S 8Ckt 300Mm Sn

  • Mfr # 2162711083

  • Zoro # G305789386

product price: $4.29
/ea
Sold in multiples of 20 for $85.80

Key Features

Insulation Material
Polyester Alloy
Maximum Voltage
600 V AC/DC
Current
3 A
Connector Type
Female-Pigtail
Material
Polyester Alloy
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
2162711083
Zoro #
G305789386
UPC #
-
Country of Origin
China

Dimensions

Length
300 mm
Max. Insulation Dia.
1.63 mm
Cable Length
300.00mm
Wire Insulation Diameter
1.63mm max.
Wire Size (AWG)
22

Details

Item
Discrete Wire Assembly
Insulation Material
Polyester Alloy
Maximum Voltage
600 V AC/DC
Current
3 A
Connector Type
Female-Pigtail
Material
Polyester Alloy
Series
216271
Color
Black
Terminal Type
Crimp or Compression
Current Rating
3 A
Features
Single Ended
Type
Discrete Wire Assembly
Application
Signal, Wire-to-Board, Wire-to-Wire
Wire Range
22 AWG
Number of Rows
1
Contact Finish
Tin Plated
Hole Center to Center
2.54 mm
Number of Contacts
8
Max. Voltage
600V AC/DC
Terminal Finish
Tin Plated
Connector to Connector
SL-to-Pigtail
Overmolded
No
Material - Resin
Polyester Alloy
Current - Maximum per Contact
3.0A
Material - Metal
Phosphor Bronze
Material - Plating Mating
Tin
Pitch - Mating Interface
2.54mm
Material - Plating Termination
Tin
Circuits (Loaded)
8
Wire/Cable Type
UL 11028
Lock to Mating Part
Yes
Product Name
SL
Single Ended
Yes
Assembly Configuration
Single Ended Connector
Termination Style
Crimp or Compression
