Shop MOLEX
See all product information
Terminal Strip, 2 Row, 600 V, 10 AWG
Mfr # 391002002
Zoro # G005918314
product price:Â $0.65
/ea
Sold in multiples of 125 for $81.25
Key Features
Number of Rows
2
Maximum Voltage
600 V
For Minimum Wire Size
18 AWG
Application
Wire-to-Wire
Color - Resin
White
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption
Specifications
Product Information
- MFR #
- 391002002
- Zoro #
- G005918314
- UPC #
- -
- Country of Origin
- China
Dimensions
- For Minimum Wire Size
- 18 AWG
- For Maximum Wire Size
- 10 AWG
Details
- Item
- Terminal Strip
- Number of Rows
- 2
- Maximum Voltage
- 600 V
- Application
- Wire-to-Wire
- Color - Resin
- White
- Temperature Range - Operating
- -40° to +105°C
- PCB Retention
- Yes
- Current - Maximum per Contact
- 30.0A
- Polarized to Mating Part
- No
- Material - Metal
- Stainless Steel
- Panel Mount
- Mounting Holes Between Circuit
- Circuits (Loaded)
- 2
- Orientation
- Vertical
- Material - Resin
- Nylon
- Lock to Mating Part
- None
- Pitch - Termination Interface
- 10.00mm
- Entry Angle
- Horizontal
- Stackable
- No
- Series
- 39100
- Component Type
- One Piece
- Product Name
- Eurostyle Two Screw
