Wire Terminal, 14 AWG, 500 V, Grey
Mfr # 7324.6008.0
Zoro # G605980773
product price: $53.35
/eaSold in multiples of 2 for $106.70
Key Features
Insulation Color
Grey
Maximum Wire Size
14 AWG
Contact Material
Copper
Maximum Voltage
500 V
Minimum Operating Temperature
-40 Degrees C
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
7324.6008.0
Zoro #
G605980773
UPC #
-
Country of Origin
Italy
Dimensions
Maximum Wire Size
14 AWG
Stripping Length
7.00mm
Component Size
24B «104X27»
Details
Item
Wire Terminal
Insulation Color
Grey
Contact Material
Copper
Maximum Voltage
500 V
Minimum Operating Temperature
-40 Degrees C
Maximum Operating Temperature
125 Degrees C
Standards
CSA C22.2 NO. 182.3, EN 60664-1, EN 61984, UL 1977, UL E249674
Series
93601
Polarized to Mating Part
Yes
Material - Plating
Silver
CSA
256883
Component Type
Inserts - Screw Terminal
Durability (mating cycles max)
700
Number of Rows
2
Tightening Test Torque
0.50 Nm
Wire Protection
Yes
Insert Series
S-E
Material - Insert
Polycarbonate
Current - Maximum per Contact
16.0A
Poles
24
