PA53 FS6 SCAN Digital Slide Scanning System

PA53 FS6 Scan - Digital Slide Scanning System Product Description: The PA53 FS6 Scan is a high-performance digital slide scanning system designed for efficient laboratory workflows. Combining precision optics with automated scanning, it enables fast, high-resolution digitization of slides for analysis, sharing, and archiving. Features: - Automated high-resolution slide scanning - Integrated fluorescence capability - Fast and efficient workflow - Digital image management compatibility - Ideal for high-throughput labs Microscopy Applications: Designed for digital pathology, research, and clinical workflows. The PA53 FS6 Scan enables rapid slide digitization for remote analysis, teaching, and archiving in modern laboratories. PA53 FS6 SCAN spec: - Scalable Infinity-Corrected Optical System (CCIS); - Dedicated PA53 Scanning Tube head with dual embedded 1.2MP and - 5MP Moticam S cameras. (LPD - 100:0, 0:100) - Wide-Field (FN23) Eyepiece 10X/23mm, diopter adjustable; - Transmitted 100W Halogen illumination; - Motorized Quintuple (5) revolving nosepiece BF (includes control box and control pad) - Reflected frame with motorized Z-axis; - Motorized Z-axis control box and control pad - Coded fluorescence turret for 6-position (5 filter sets and 1 BF) - Plan UC 2X / 0.05 (WD=7.2mm) - Plan UC Fluor 10X/0.3,W.D=11.7mm,CG=0.17 - Plan UC Fluor 20X/0.5,W.D=2.2mm,CG=0.17 - Plan UC Fluor 40X/0.75,W.D=0.7mm,CG=0.17 - AT-DAPI/Hoechst/AlexaFluor 350 SET - AT-EGFP/FITC/Cy2/AlexaFluor 48 SET - AT-TRITC/Cy3/TagRFP/AlexaFluor 546 SET - Two (2) empty filter cube sets - ScanPlus 100 x 100mm MOT XY Stage, w/linear measuring system, max travel speed 240 mm, control box and two axes joystick (Check on delivery time) - Achromat Swing-out Condenser, N.A. 0.90 / 0.13 - Software Motic VM 3.0 for PA53 Bio Scan with dongle - Integrated power supply for 12V/100W light adjustment, voltage indicator, IL and ECO function, Allen keys
