Active Ethernet I/O Server, 6Di/6Relay, Iologik E2214-T

  • Mfr # ioLogik E2214-T

  • Zoro # G4571560

product price:
$
740.99
/ea
Free Shipping & Returns

Key Features

Mounting
DIN rail or wall
Power Consumption
170 mA @ 24 VDC
Shock
IEC 60068-2-27
Freefall
IEC 60068-2-32
Ambient Relative Humidity
5 to 95% (non-condensing)
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
ioLogik E2214-T
Zoro #
G4571560
UPC #
-
Country of Origin
Taiwan, Province of China

Dimensions

Dimensions
115 x 79 x 45.6 mm (4.53 x 3.11 x 1.80 in)

Details

Mounting
DIN rail or wall
Power Consumption
170 mA @ 24 VDC
Shock
IEC 60068-2-27
Freefall
IEC 60068-2-32
Ambient Relative Humidity
5 to 95% (non-condensing)
Mechanical Endurance
1,000,000 operationsElectrical endurance: 100,000 operations @ 5 A resistive load
Dry Contact
On: short to GND; Off: open
Pulse Output
0.3 Hz at rated load
Minimum permitted load
1 A @ 5 VDC
Altitude
Up to 2000 m
Protection
1.5 kV magnetic isolation
Initial Insulation Resistance
1000 M ohms (min.) @ 500 VDC
EMS
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4; EN 61000-4-5, EN 61000-4-6, EN 61000-4-8; EN 61000-4-11, EN 61000-6-2
Isolation
3k VDC or 2k Vrms
Operating temperature
Standard Models: -10 to 60°C (14 to 140°F); Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Sensor Type
Wet Contact (NPN or PNP) and Dry Contact
I/O Mode
DI or Event Counter
Baudrate
1200 to 115200 bps
Type
Form A (N.O.) power relay
Digital Inputs
6 channels
Database
Telcordia (Bellcore)
Contact Current Rating
Inductive Load: 2 A @ 30 VDC, 250 VAC, 110 VAC; Resistive Load: 5 A @ 30 VDC, 250 VAC, 110 VAC
Ethernet
1 10/100 Mbps RJ45 port
Protocols
Modbus/TCP, TCP/IP, UDP, DHCP, BOOTP, SNMP, HTTP, CGI, SNTP, SMTP
Stop Bits
1
Vibration
IEC 60068-2-6
Relay Outputs
6 channels
Wiring
I/O cable max. 14 AWG
Serial Line Protection
15 kV ESD for all signals
Wet Contact (DI to GND)
On: 0 to 3 VDC; Off: 10 to 30 VDC
Data Bits
8
Power Input
24 VDC nominal, 12 to 36 VDC
Interface
RS-485-2w: Data+, Data-, GND (3-contact terminal block)
EMI
EN 61000-3-2; EN 61000-3-3; EN 61000-6-4; FCC Part 15, Subpart B, Class A
Counter Frequency
900 Hz
Time
307,239 hrs
Storage temperature
-40 to 85°C (-40 to 185°F)
Protocol
Modbus/RTU
Contact Resistance
100 m ohms (max.)
Parity
None
Digital Filtering Time Interval
Software Configurable
Safety
UL 508
Common Type
3 points per COM

Description

Active Ethernet I/O server, 6DI/6Relay
