- MFR #
- ioLogik E1242
- Zoro #
- G4573679
- UPC #
- -
- Country of Origin
- Taiwan, Province of China
- Mounting
- DIN rail or wall
- Protection
- 1.5 kV magnetic isolation
- Pulse Output Frequency
- 500 Hz
- EMI
- EN 55022; EN 61000-3-2; EN 61000-3-3; FCC Part 15, Subpart B, Class A
- Storage temperature
- -40 to 85°C (-40 to 185°F)
- Type
- Differential input, Sink
- Isolation
- 3k VDC or 2k Vrms
- Ambient Relative Humidity
- 5 to 95% (non-condensing)
- Shock
- IEC 60068-2-27
- Time
- 502,210 hrs
- Accuracy
- ±0.1% FSR @ 25°C; ±0.3% FSR @ -10 and 60°C; ±0.5% FSR @ -40 and 75°C
- Dry Contact
- On: short to GND; Off: open
- Input Impedance
- 10M ohms (min.)
- Over-voltage Protection
- 45 VDC
- Analog Inputs
- 4 channels
- Digital Inputs
- 4 channels
- Counter Frequency
- 250 Hz
- Input Range
- 0 to 10 VDC, 0 to 20 mA, 4 to 20 mA
- Built-in Resistor for Current Input
- 120 ohms
- Wiring
- I/O cable max. 14 AWG
- Common Type
- 4 points per COM
- Freefall
- IEC 60068-2-32
- Database
- Telcordia (Bellcore)
- Current Rating
- 200 mA per channel
- I/O Mode
- DI or Event Counter, Voltage / Current, DO or Pulse Output
- Over-temperature Shutdown
- 175°C (typical), 150°C (min.)
- Digital Filtering Time Interval
- Software Configurable
- Power Input
- 24 VDC nominal, 12 to 36 VDC
- Power Consumption
- 139 mA @ 24 VDC
- EMS
- EN 55024, EN 61000-4-2, EN 61000-4-3; EN 61000-4-4, EN 61000-4-5, EN 61000-4-6; EN 61000-4-8, EN 61000-4-11
- Sampling Rate
- All channels: 12 samples/sec; Per channel: 3 samples/sec; Only one channel enabled: 12 samples/sec
- Altitude
- Up to 2000 m
- Sensor Type
- Wet Contact (NPN or PNP), Dry Contact
- Operating temperature
- Standard Models: -10 to 60°C (14 to 140°F); Wide Temp. Models: -40 to 75°C (-40 to 167°F)
- Vibration
- IEC 60068-2-6
- Ethernet
- 2 switched 10/100 Mbps RJ45 ports
- Configurable DI/Os
- 4 channels
- Resolution
- 16 bits
- Protocols
- Modbus/TCP, TCP/IP, UDP, DHCP, BOOTP, HTTP
- Safety
- UL 508
- Hazardous Location
- UL/cUL Class I Diision 2, ATEX Zone 2
- Over-current Protection
- 2.6 A (4 channels @ 650 mA)
- Wet Contact (DI to COM)
- On: 10 to 30 VDC; Off: 0 to 3 VDC
