Moxa Rs-485 Remote I/O, 8 Ais, -10 To 75 DegreeC Operating Temperature. ioLogik R1240 - main

Rs-485 Remote I/O, 8 Ais, -10 To 75 DegreeC Operating Temperature.

  • Mfr # ioLogik R1240

  • Zoro # G4576375

product price:  $423.99
/ea
Free Shipping & Returns

Key Features

Sampling Rate (all channels)
12 Hz
Dimensions
27.8 x 124 x 84 mm (1.09 x 4.88 x 3.31 in)
Type
Differential input
Safety
UL 508
Resolution
16 bits
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
ioLogik R1240
Zoro #
G4576375
UPC #
-
Country of Origin
Taiwan, Province of China

Dimensions

Dimensions
27.8 x 124 x 84 mm (1.09 x 4.88 x 3.31 in)

Details

Sampling Rate (all channels)
12 Hz
Type
Differential input
Safety
UL 508
Resolution
16 bits
Storage temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative Humidity
5 to 95% (non-condensing)
Accuracy
±0.1% FSR @ 25°C; ±0.3% FSR @ -10 and 60°C; ±0.5% FSR @ -40 and 75°C
Interface
RS-485-2w: Data+, Data-, GND (5-contact terminal block for two serial port)
Operating temperature
Standard Models: -10 to 75°C (14 to 167°F); Wide Temp. Models: -40 to 85°C (-40 to 185°F)
Analog Inputs
8 channels
High/Low Resistor for RS-485
1 kΩ, 150 kΩ
EMI
EN 55022, EN 61000-3-2, EN 61000-3-3, FCC Part 15 Subpart B Class A
Shock
IEC 60068-2-27
Power Consumption
216 mA @ 24 VDC
Serial Line Protection
ESD Protection: 15 kV; Surge Protection: 1 kV
Built-in Resistor for Current Input
120 ohms
Freefall
IEC 60068-2-32
Baudrate
1200 to 921.6 kbps (default = 9600)
Input Impedance
10M ohms (min.)
Parity
None, Even, Odd (default = None)
Protocols
Modbus RTU
EMS
EN 55024, EN 61000-4-2 (ESD) Level 3, EN 61000-4-5 (Surge) Level 2; IEC 61000-4, IEC 61000-6
I/O Mode
Voltage / Current
Vibration
IEC 60068-2-6
Input Range
0 to 10 VDC, 0 to 20 mA, 4 to 20 mA (burn-out mode)
Stop Bits
1, 2 (default = 1)
Data Bits
8
Isolation
3k VDC or 2k Vrms
Wiring
I/O cable max. 16 AWG

Description

RS-485 remote I/O, 8 AIs, -10 to 75°C operating temperature.
