  11. Elbow, 1/4 in Tube Size, Polybutylene, White, 10 PK
This item is Discontinued.
Norgren Elbow, 1/4 in Tube Size, Polybutylene, White, 10 PK M00400600

Elbow, 1/4 in Tube Size, Polybutylene, White, 10 PK (Discontinued)

  • Mfr # M00400600
  • Zoro # G0666635
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
M00400600
Zoro #
G0666635
UPC #
746350065374
Country of Origin
Korea, Republic of

Dimensions

Tube Size
1/4 in
Fitting Side A Tube Outer Diameter
6 mm
Fitting Side B Tube Outer Diameter
6 mm
Fitting Side 2 Tube Outer Diameter
6 mm
Fitting Side 1 Tube Outer Diameter
6 mm

Details

Item
Elbow
Tube Fitting Material
Polybutylene
Specific Fitting Shape
90 Degrees Elbow
Fitting Connection Type
Tube
Max. Pressure
150 psi
Basic Pipe Fitting Shape
Elbow
Color
White
Basic Pipe Fitting Material
Plastic
Pipe Fitting Connection Type
Tube
Temp. Range
32 Degrees to 140 Degrees F
Specific Pipe Fitting Shape
90 Degrees Elbow
System of Measurement
Metric
Application
Air
Compatible Tube Material
Nylon, Polyurethane
Fitting Material
Polybutylene
Resistance Properties
Impact-Resistant
Maximum Operating Pressure
150 psi
Release Ring Material
POM
Release Type
Sleeve
Maximum Operating Temperature
140 Degrees F
Thread Sealant Type
Chemiseal G 175
Minimum Operating Temperature
32 Degrees F
Fitting Side A Connection Type
Push-to-Connect
Fitting Side B Connection Type
Push-to-Connect
Fitting Shape
90 Degrees Elbow
Fitting Side 1 Connection Type
Push-to-Connect
Fitting Side 2 Connection Type
Push-to-Connect
For Media Type
Air
Operating Temperature - Maximum
140 Degrees F
Operating Temperature - Minimum
32 Degrees F
Operating Pressure - Maximum
150 psi

Description

Elbow, Application Air, Fitting Side A Connection Type Push-to-Connect, Fitting Side B Connection Type Push-to-Connect, Fitting Side A Tube Outer Diameter 6 mm, Fitting Side B Tube Outer Diameter 6 mm, Fitting Material Polybutylene, Color White, Maximum Operating Pressure 150 psi, Maximum Operating Temperature 140 Degrees F, Specific Fitting Shape 90 Degrees Elbow, Release Type Sleeve, Compatible Tube Material Nylon, Polyurethane, Minimum Operating Temperature 32 Degrees F
