Shop NOSHOK

Pressure Switch, Standard, SPDT, 1/4" NPT, Die-Cast Zinc

  • Mfr # 400L-3-2-3/30-8
  • Zoro # G808571723
product price:
$
127.99
/ea
Free Shipping & Returns

Key Features

Action
Snap
Contact Form
SPDT
Pressure Connection Type
1/4 in NPT
Range
3 to 30 psi
Housing Material
Die-Cast Zinc
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
400L-3-2-3/30-8
Zoro #
G808571723
UPC #
-
Country of Origin
Germany
Item
Pressure Switch
Action
Snap
Contact Form
SPDT
Pressure Connection Type
1/4 in NPT
Range
3 to 30 psi
Housing Material
Die-Cast Zinc
Factory On Setting
3 psi
Factory Off Setting
30 psi
Standards
European Conformity (CE) Compliant to European Standard (EN) 73/23/EWG Radio Frequency Interference (RFI), Electromagnetic Interference (EMI) and Electrostatic Discharge (ESD) Protection
IP Rating
IP65
Ambient Temp. Range
-4 Degrees to 176 Degrees F
Series
400
Max. Pressure
300 to 5000 psig
Media Temp. Range
-4 to 176°F
Wetted Materials
Stainless Steel, NBR
Electrical Connection
DIN EN 175301-803 Form A

Description

400 Series Mechanical Heavy-Duty Pressure Switch, 1 SPDT Switch, 7/16-20 SAE J514 FIG 34B, 3 psig to 30 psig 870 psig, Hirschmann. Switch adjustment ranges from vacuum through 4,600 psig depending on model. Standard Zinc-plated Steel with NBR diaphragm < 225 psig; Steel piston with NBR seal > 225 psig wetted parts. SPDT snap-action switch. RoHS compliant.
