Flange Bearing, 4-Bolt, Ball, 1-15/16" Bore
Mfr # SUCF210-31
Zoro # G2738574
product price:Â
$
579.99
/ea
Free Shipping & Returns
Key Features
System of Measurement
Inch
Housing Type
Square
Number of Mount Holes
4
Bearing Insert Type
Radial Ball
Shaft Locking Type
Set Screw
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- SUCF210-31
- Zoro #
- G2738574
- UPC #
- -
- Country of Origin
- Multiple
Dimensions
- Bolt Size
- M14
- Bore Diameter
- 1-15/16 in
- Mount Hole Center-to-Center Length
- 4-7/16 in
- Overall Length
- 5-5/8 in
- Overall Width
- 2-5/32 in
- Overall Height
- 5-5/8 in
- Flange Thickness
- 19/32 in
- Dimension A
- 143 mm
- Dimension S
- 16 mm
- Dimension L
- 40 mm
- Dimension G
- 16 mm
- Dimension N
- 19 mm
- Dimension E
- 111 mm
- Mount Hole Size
- 0.63 in
- Mount Hole Center-to-Center Height
- 4 7/16 in
- Back Side to Center Width
- 0.866 in
- Mounting Bolt Size
- 1/2, M14
- Wire Rope Length
- 5 5/8 in
- Inner Ring Width
- 2.03 in
- Center Height
- 2 13/16 in
- Length
- 5 5/8 in
Description
Flange Mount Bearing, Back Side to Center Width 0.866 in, Bearing Insert Material Stainless Steel, Bearing Insert Type Radial Ball, Bore Diameter 1 15/16 in, Bore Type Cylindrical, Center Height 2 13/16 in, Closure Double Sealed, Expansion Type Fixed, For Environment Food and Beverage, Washdown, Housing Material Stainless Steel, Housing Type Square, Included Bearing SUC210-31, Lubricant Material H-1 Food Grade Solid Lubricant, Maximum Speed 2,900 RPM, Maximum Temperature 212 Degrees F
