Stainless Steel Four Bolt Flange
Mfr # SUCF208C0FG1
Zoro # G223781769
product price:Â
$
610.99
/ea
Free Shipping & Returns
Key Features
Minimum Temperature
-4 Degrees F
Mount Hole Center-to-Center Length
102 mm
Includes Bearing Cap
Bearing Cap Included
Bearing Lubrication
Maintenance-Free
Number of Mount Holes
4
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- SUCF208C0FG1
- Zoro #
- G223781769
- UPC #
- -
- Country of Origin
- Multiple
Dimensions
- Mount Hole Center-to-Center Length
- 102 mm
- Center Height
- 65 mm
- Mounting Bolt Size
- 1/2, M14
- Overall Length
- 130 mm
- Flange Thickness
- 14.5 mm
- Overall Width
- 54.7 mm
- Back Side to Center Width
- 21 mm
- Mount Hole Center-to-Center Height
- 102 mm
- Bore Diameter
- 40 mm
- Mount Hole Size
- 16 mm
- Overall Height
- 130 mm
- Inner Ring Width
- 49.2 mm
- Length
- 130 mm
Description
Flange Mount Bearing, Back Side to Center Width 21 mm, Bearing Insert Material Stainless Steel, Bearing Insert Type Radial Ball, Bore Diameter 40 mm, Bore Type Cylindrical, Center Height 65 mm, Closure Double Sealed, Expansion Type Fixed, For Environment Food and Beverage, Housing Material Stainless Steel, Housing Type Square, Included Bearing SUC208FG1, Lubricant Material H-1 Food Grade Solid Lubricant, Maximum Temperature 212 Degrees F, Minimum Temperature -4 Degrees F
