  9. Temperature Probe, Mini Plug, Type K
Oakton Temperature Probe, Mini Plug, Type K WD-08516-95 - main

Temperature Probe, Mini Plug, Type K

  • Mfr # WD-08516-95

  • Zoro # G4672735

product price: $152.99
/ea
Free Shipping & Returns

Key Features

Sensor Type
Thermocouple
Temp. Range (F)
-418 Degrees to 932 Degrees
Temp. Range (C)
-250 Degrees to 500 Degrees
Probe Length
10.5 in
Primary Measuring Element
Thermocouple
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
WD-08516-95
Zoro #
G4672735
UPC #
-
Country of Origin
United States

Dimensions

Probe Length
10.5 in
Probe Wire Length
5 ft
Wire Length
5 ft.
Probe Size
10 1/2 in
Cable Length
60 in

Details

Item
Surface Temperature Probe
Sensor Type
Thermocouple
Temp. Range (F)
-418 Degrees to 932 Degrees
Temp. Range (C)
-250 Degrees to 500 Degrees
Primary Measuring Element
Thermocouple
Probe Temp. Measuring Element
K Thermocouple
Probe Connector
Mini
Probe Connection Type
Mini
Probe Contact Material
304 Stainless Steel
Accuracy
+/-3.0 Degrees F (1.1 Degrees C) or +/-0.4% Reading Above 212 Degrees F(100 Degrees C), +/-3.6 Degrees F (2.2 Degrees C) or 2% of Reading Between -58 to 211 Degrees F (-50 to 99 Degrees C), +/-7.2 Degrees F (4 Degrees C) or +/-4% of Reading Between -60 to -238 (-51 to -150 Degrees C)
Use
Moving Surfaces
Response Time
1.7 sec
Process Connection
1/4 in NPT, Compression Fitting
Temperature Measuring Element
K Thermocouple
Probe Material
304 Stainless Steel
Maximum Temperature F
900 Degrees F
For Liquids and Gels
No
Junction Type
Exposed
Temperature Range
-250 Degrees to 900 Degrees F/-150 Degrees to 482 Degrees C
Minimum Temperature C
-150 Degrees C
Includes Thermowell
No
For Solids
No
Head Material
ABS Plastic
Process Mounting
1/4 in NPT Compression
Handle Material
ABS Plastic
Minimum Temperature F
-250 Degrees F
For Application
Surface
Thermowell Connection
Mini Connector
Thermocouple Type
Type K
Probe Sheath Material
316 Stainless Steel
Probe Bend
Straight
For Gases
No
Connector Type
Mini Plug
Tip Style
Bow-Type
For Surfaces
Yes
Handle Type
Straight Handle
For Air
No
Maximum Temperature C
482 Degrees C
Minimum Temperature °C
-150 Degrees C
Minimum Temperature °F
-250 Degrees F
Maximum Temperature °C
482 Degrees C
Maximum Temperature °F
900 Degrees F
Maximum Temperature °F
900 Degrees F
Minimum Temperature °C
-150 Degrees C
Minimum Temperature °F
-250 Degrees F
Maximum Temperature °C
482 Degrees C

Description

Surface Temperature Probe, Type K, Exposed, For Application Surface, 1/4 in NPT Compression, Mini Plug, Probe Size 10 1/2 in, Cable Length 60 in, -250 Degrees to 900 Degrees F/-150 Degrees to 482 Degrees C, Thermocouple, Thermowell Connection Mini Connector
