Fiber Optic Cable, Through Beam, 500mm
Mfr # E32-T51
Zoro # G0351346
product price: $188.99
/ea
Free Shipping & Returns
Key Features
Cable Diameter
2.2 mm
Standards
IEC, UL Listed
Min. Object Size
0.100mm dia
Fiber Material Core
Plastic
Cable Dia.
2 mm
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
E32-T51
Zoro #
G0351346
UPC #
-
Country of Origin
Japan
Dimensions
Cable Diameter
2.2 mm
Min. Object Size
0.100mm dia
Cable Dia.
2 mm
Cable Length
2 m
Object Diameter - Minimum
0.1 mm
Beam Diameter
4 mm
Details
Item
High Temperature Fiber Optic Cable
Standards
IEC, UL Listed
Fiber Material Core
Plastic
Temp. Range
-40 Degrees to 302 Degrees F
Max. Sensing Distance
500 mm
Sheath
Fluoride Resin
Tip Type
M4 Screw
Sensing Method
Through-Beam
Product Type
High Temperature Fiber Optic Cable
Sensing Surface Orientation
Top View
Compatible with Brand
Omron
Operating Temperature - Maximum
302 Degrees F
Sensing Distance - Maximum
400 cm
Compatible Product Type
Fiber Optic Sensors
Cable Connection Type
M4 Screw
Operating Temperature - Minimum
-40 Degrees F
Sheath Material
Fluororesin
Description
High Temperature Fiber Optic Cable, Through-Beam Sensing Method, Cable Length 2 m, Max. Sensing Distance 500 mm, Min. Object Size 0.100mm dia, Sheath Fluoride Resin, Fiber Material Core Plastic, Temp. Range -40 Degrees to 302 Degrees F, Cable Dia. 2 mm, Tip Type M4 Screw, Standards IEC, UL Listed
