  11. Power Supply, 100/240V AC, 24V DC, 240 W, 10 A, DIN Rail
No Product Image Available

Power Supply, 100/240V AC, 24V DC, 240 W, 10 A, DIN Rail

  • Mfr # S8VK-X24024A-EIP

  • Zoro # G809769150

product price: $749.99
/ea
Free Shipping & Returns

Key Features

Input Voltage
100/240V AC
Output Voltage - Nominal
24V DC
Output Power - Rated
240 W
Current - Output
10 A
Mounting
DIN Rail
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
S8VK-X24024A-EIP
Zoro #
G809769150
UPC #
4549734172738
Country of Origin
China

Dimensions

Overall Height
38 mm
Overall Width
124 mm
Overall Depth
121.4 mm
Height
124 mm
Width
38 mm
Depth
121.4 mm

Details

Item
Power Supply
Input Voltage
100/240V AC
Output Voltage - Nominal
24V DC
Output Power - Rated
240 W
Current - Output
10 A
Mounting
DIN Rail
Phase
Single
Power Supply Style
Switching
Output Noise
130 mV
Status Indicator
Green (Output), Red (Alarm)
IP Rating
IP20
Output Voltage
24V DC
Hold Up Time
35 msec
Style
Switching
Series
S8VK-X
Power Rating
240W
Output Amps
15A
Hz
50/60 Hz
Phase - Electrical
Single
Standards
EN/IEC 60529
Current - Peak
15 A
Manufacturer Warranty
5 yr
Start Up Time - Maximum
1,000 msec
Input Frequency - Nominal
50/60 Hz
Special Features
Alarm Indication, LED Diagnostic Indicators, Overload Protection, Overvoltage Protection, Parallel Capability, Peak-Hold Current Indication, Series Operation, Total Run Time Monitor
Maximum Efficiency @ 230V AC
93 %
Mean Time Between Failures (MTBF)
100,000 hr
Wire Connection Type
Push In
Operating Temperature - Minimum
-40 Degrees F
Current - Inrush
32 A
Maximum Efficiency @ 115V AC
91 %
Operating Temperature - Maximum
158 Degrees F

Description

DC Power Supply, Input Voltage 100 to 240V AC, Mounting DIN Rail, Series S8VK-X, IP Rating IP20, Status Indicator Green (Output), Red (Alarm), Standards EN/IEC 60529
