  13. W-Bracket, General Purpose Relay, 10.8 mA, 10 Pins, Screw
Omron W-Bracket, General Purpose Relay, 10.8 mA, 10 Pins, Screw G7J-4A-B AC200/240 - main

W-Bracket, General Purpose Relay, 10.8 mA, 10 Pins, Screw

  • Mfr # G7J-4A-B AC200/240

  • Zoro # G210080196

product price: $78.79
/ea
Free Shipping & Returns

Key Features

Mounting Style
W-Bracket
Electrical Connection
Screw
Number of Pins
10
Coil Voltage
200/240V AC
Current Rating
10.8 mA
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
G7J-4A-B AC200/240
Zoro #
G210080196
UPC #
4547648393683
Country of Origin
China

Dimensions

Body Width
2.02 in
Mounting Hole Diameter
4.5 mm
Body Depth
1.35 in
Body Height
2.17 in
Flat Pin Width
7.6 mm
Overall Depth
1.35 in

Details

Item
General Purpose Relay
Mounting Style
W-Bracket
Electrical Connection
Screw
Number of Pins
10
Coil Voltage
200/240V AC
Current Rating
10.8 mA
Contact Form
4PST-NO
Contact Rating (AC)
25 A @ 240V
Contact Rating (DC)
100.00 mA @ 24V, 25 A @ 30V
Features
Can Be Used Like a Contactor, Compatible with Momentary Voltage Drops
Contact Material
Silver Alloy
Standards
CSA (File No. LR35535), CSA Approval: CSA C22.2 No. 14 for Industrial Control Devices, UL (File No. E41643), UL Approval: UL508 for Industrial Control Devices
Maximum Operating Temperature
60 Degrees C
Power Consumption
2.6 VA
Horsepower @ 240V AC
3 hp
For Use With
Contactors
Response Time
50 msec
Dielectric Strength
2000 V AC, 50/60 Hz for 1 Minute Between Contacts of the Same Polarity, 4000 V AC, 50/60 Hz for 1 Minute Between Coil and Contacts, 4000 V AC, 50/60 Hz for 1 Minute Between Contacts of Different Polarity
Series
G7J Series
Minimum Operating Temperature
-25 Degrees C
Electrical Operating Durability
100,000
Mechanical Operating Durability
1,000,000
Push-To-Test Method
Manual Push Test Button
Insulation Resistance
1,000 megaohm
Minimum Switching Current
25 A
Horsepower @ 120V AC
1 1/2 hp
Frequency
50/60 Hz
Weight
165 g
Maximum Switching Voltage
250V AC
Resistance Properties
Flame-Resistant

Description

General Purpose Relay, Coil Voltage 200/240V AC, Contact Form 4PST-NO, Current Rating 9 mA, 10.8 mA, Electrical Connection Screw Terminal, Flat Pin Width 7.6 mm, Number of Pins 10, Contact Rating (AC) 25 A @ 240V, Contact Rating (DC) 100.00 mA @ 24V, 25 A @ 30V, Horsepower @ 120V AC 1 1/2 hp, Horsepower @ 240V AC 3 hp, Mounting Style W-Bracket, Push-To-Test Method Push Button, Body Depth 1.35 in, Body Height 2.17 in, Body Width 2.02 in, Contact Material Silver Alloy
