Straight Flute Hand Tap, 1/4"-20, Modified Bottoming, 4 Flutes, UNC

  • Mfr # 1005111408
  • Zoro # G9241364

product price:
$
47.99
/ea

Key Features

Shank Dia.
0.191"
Tap Material
Powdered Metal
Tap Chamfer
Modified Bottoming
Tap Size
1/4"
Tap Style
Straight Flute (Hand)
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
1005111408
Zoro #
G9241364
UPC #
-
Country of Origin
Japan
Item
Straight Flute Hand Tap
Tap Material
Powdered Metal
Tap Chamfer
Modified Bottoming
Tap Style
Straight Flute (Hand)
Number of Flutes
4
Thread Direction
Right Hand
Tap Thread Type
UNC
Number of Pieces
1
Tap Finish
TiCN
List Number
10051
Tap Grouping
Tap
Series
10051
Cutting Direction - Machining
Right Hand
Thread Limit
H5
Threads per Inch
20
Spiral Direction
Neutral
Coolant Fed
Non-Coolant Through
Measurement System
Fractional Inch
Shank Type - Machining
Straight
Extended Neck
Yes
Primary Material Application
Hardened Steel
Secondary Material Application
Steel
Primary Material Application ISO Code
H
Thread Standard
UNC
Secondary Material Application ISO Code
P
Helix Angle
0 Degrees
Tap Application
Blind Hole, Through Hole
Class of Fit
2B-3B
Shank Type
Square

Dimensions

Shank Dia.
0.191"
Tap Size
1/4"
Tap Dimension Type
Inch
Overall Length
2-1/2"
Thread Length
1"
Tap Thread Size
1/4"-20
Pitch Diameter Limit
H5
55% Thread Drill Size
#3
Thread Size
1/4"-20
75% Thread Drill Size
#7
Shank Length
1 1/2 in
Square Size
0.1900 in
65% Thread Drill Size
#5
Size
1/4"
Neck Length
1 in
Square Width
0.19 in
Square Length
0.31 in
Shank Diameter
0.255 in
Wire Rope Length
2.5 in
Length
2.5 in

Description

Straight Flute Tap, Thread Size 1/4 In.-20, UNC, Modified Bottoming, Overall Length 2.5 in, Powdered Metal, V, Right Hand, Thread Length 0.6 in, 75 Percent Thread Drill Size #7, Thread Limit H5, Class of Fit 2B-3B
