Palmgren Hydraulic Press, Manual, Overall 76" H 9661613 - main

Hydraulic Press, Manual, Overall 76" H

  • Mfr # 9661613

  • Zoro # G7124728

product price: $3,378.99
/ea
Additional $125.00 delivery surcharge applies per item.
See details

Key Features

Frame Capacity
25 ton
Frame Type
H-Frame
Cylinder Stroke
10 in
Pump Type
Hydraulic Manual
Base Length
27 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
9661613
Zoro #
G7124728
UPC #
00194484265694
Country of Origin
China

Dimensions

Base Length
27 in
Base Width
20 in
Overall Height
62 in
Height with Screw Extension
76"
Working Width
19-1/4"
Working Height
25"
Hose Length
5 ft 6 in
Total Height
76"
Total Width
30"
Bed Height
30"
Overall Width
14 in
Overall Length
35 in
Overall Depth
35 in
Press Bed Depth
8 1/8 in
Press Bed Width
19 1/4 in
Base Depth
27 in
Hydraulic Hose Length
66 in

Details

Frame Capacity
25 ton
Frame Type
H-Frame
Cylinder Stroke
10 in
Pump Type
Hydraulic Manual
Item
Hydraulic Press
Features
Heavy Duty;Welded Channel Frame
Reservoir Capacity
2.5 qt
Application
Bending, Clamping, Forming, Pressing Bearings, Punching, Staking, Straightening
Includes
Table Plates, V-Blocks
Pump Handle Effort @ Rated Capacity (Lb.)
25 lb.
Strokes to Extend Piston 1 In
10
Cylinder Type
Single Acting
Cylinder
Fixed
Pump
Hydraulic
Distance Between Uprights
19 1/4 in
Pressure
25 tons
Stroke
10 in
Material - Machining
Iron
Operating Pressure
25 Tonf
Pump Model Number
Hydraulic
Operation
Manual
Frame Material
Iron
Ram-to-Table Distance - Maximum
28 3/8 in
Capacity
25 ton
Ram-to-Table Distance - Minimum
3 in

Description

Hydraulic Press, Pump Type Hydraulic Manual, Frame Type H-Frame, Frame Capacity 25 ton, Cylinder Type Single Acting
