Shop PANDUIT

Butt Splice Wire Connector, Purple, None Insulation, 35 kV

  • Mfr # SCMS95-Q
  • Zoro # G2997455
product price:
$
9.79
/ea

Key Features

Type
Butt Splice
Color
Bare
Minimum Wire Size
70 mm²
Insulation Material
None
Maximum Voltage
35 kV
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
SCMS95-Q
Zoro #
G2997455
UPC #
7498376990
Country of Origin
India

Dimensions

Maximum Wire Size
95 mm²
Minimum Wire Size
70 mm²
Overall Length
2.12 in
Wire Strip Length (mm)
28.5
Barrel Length (In.)
2.12
Metric Class 5f-6f Copper Conductor Size (mm²)
70
Metric Class 2r Copper Conductor Size (mm²)
95

Details

Item
Wire Connector
Type
Butt Splice
Color
Bare
Insulation Material
None
Maximum Voltage
35 kV
Maximum Operating Temperature
90 Degrees C
RoHS Compliant
Yes
Standards
UL Listed, CSA Certified, CE and tested per EN 61238-1:2003/IEC 61238-1:2003 Class B, with Class 2r wire 10mm² - 630mm²., UKCA compliant
Material
Copper
Finish
Tin Plated
CSA Temperature Rating (°C)
90
Barrel Type
Standard
Panduit Die Index Number
P54

Description

Copper Compression Metric Butt Splice, 95mm2 Wire
