This item is Discontinued.

Panduit Cat 5E Leadframe Jack Module (25 Pack), 25PK NK5E88MRD-Q

Cat 5E Leadframe Jack Module (25 Pack), 25PK (Discontinued)

  • Mfr # NK5E88MRD-Q
  • Zoro # G504858630
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
NK5E88MRD-Q
Zoro #
G504858630
UPC #
7498399724
Country of Origin
China

Dimensions

Width
0.65 in
Height
0.87 in
Depth
1.37 in
Overall Length
1.37 in
Overall Width
0.65
Overall Height
0.87
Height (in.)
0.87
Depth (in.)
1.37

Details

Material
Module housing - ABS, Wire cap - Polycarbonate
Color
Red
Termination Type
Leadframe
Type
Jack Module
Connector Type
Jack Module
Application
Unshielded
Standards
Exceeds Channel and Component Requirements of ANSI/TIA-568.2-D and ISO 11801 Standards for the Respective Category, Meets IEC 60603-7, Supports 2500 Connection Cycles with IEEE 802.3af / 802.3at and 802.3bt Type 3 and Type 4, UL 1863 and UL 2043 and RoHS Compliant.
Storage Temperature
-40°F to 158°F (-40°C to 70°C)
Performance Level
Category 5e/Class D
Brand or Series
NetKey
Operating Temperature
14°F to 140°F (-10°C to 60°C)
Modular Jack Type
Keystone Jack Module
Connection Type
Insulation displacement
No. of Module Spaces
1
Module Form Factor
Keystone
Module Type
Keystone Style
Wiring Scheme
T568A/T568B
Termination Style
Leadframe
No. of Ports
1
Model (Design)
Bus

Description

The NetKey Cat 5e UTP RJ45 Leadframe Keystone Jack Module is designed to terminate 4-pair, 22-24 AWG twisted pair cable. Each module is 100% factory tested for continuity. Contacts are plated with 50 microinches of gold for superior performance. Jack modules are compatible with keystone interfaces including NetKey Faceplates, Modular Patch Panels, and Surface Mount Boxes. This jack module is red and includes 25 per package.
