This item is Discontinued.

Panduit Jack, Mini Com, Cat 5e, Off White CJ5E88TIW

Jack, Mini Com, Cat 5e, Off White (Discontinued)

  • Mfr # CJ5E88TIW
  • Zoro # G0621862
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
CJ5E88TIW
Zoro #
G0621862
UPC #
074983771349
Country of Origin
United States

Dimensions

Width
0.624 in
Depth
1.432 in
Height
0.712 in
Overall Height (In.)
0.71
Overall Width (In.)
0.62
Overall Length (In.)
1.43
Overall Depth (In.)
1.43
Overall Height (mm)
18
Overall Width (mm)
15.7
Overall Length (mm)
36.3
Overall Depth (mm)
36.3
Overall Height
11/16 in
Overall Width
5/8 in
Overall Depth
1 7/16 in

Details

Item
Modular Jack
Series
Mini Com
Cable Type
CAT5e
Material
Plastic
Color
Off-White
For Use With
Mini-Com Faceplate and Panels
Number of Ports
1
Termination Type
Tool-Less
Connector Type
Jack Module - Standard
Termination Style
TP Style
Standards Met
Exceeds Channel and Component Requirements of ANSI/TIA-568.2-D and ISO 11801 Standards for the Respective Category, Meets IEC 60603-7, Supports 2500 Connection Cycles with IEEE 802.3af / 802.3at and 802.3bt Type 3 and Type 4, UL 1863 and UL 2043 and RoHS Compliant.
Body Material
ABS
Contact Material
Plated Phosphor Bronze
Maximum Operating Temperature (°C)
65
Module Type
Mini-Com®
Shield Type
Unshielded (UTP)
Product Type
Network Connector
Minimum Operating Temperature (°C)
-10
Minimum Storage Temperature (°C)
-40
Maximum Storage Temperature (°C)
70
Performance Level
Category 5e
Resistance Properties
Flame/Fire Resistant
Wiring Scheme
T568A/T568B
Compatibility
<b>Panduit Mini-Com :</b></li> </ul>Modular Patch Panels</li><li>Faceplates</li><li>Surface Mount Boxes</li></ul>
Product Name
Mini-Com TX-5e Modular Insert
Product Line
Mini-Com
Connector Details
1 x RJ-45 Network Female
Product Color
Off White
Certifications & Standards
TIA/EIA-568-B.2
Maximum Storage Temperature (°F)
158
Maximum Operating Temperature (°F)
149
Minimum Storage Temperature (°F)
-40
Minimum Operating Temperature (°F)
14
Sub Brand
Pan-Net®
Compatible Connector Type
RJ45
Compatible Cable Performance Category
5e
RCA Insulator Color
Off-White
Standards
ANSI/TIA-568.2-D, IEC 60603-7, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt Type 3 and Type 4, ISO 11801, RoHS Compliant, UL 1863, UL 2043

Description

Modular Jack, Termination Type Tool-Less, Compatible Cable Performance Category 5e, Compatible Connector Type RJ45, Color Off-White, RCA Insulator Color Off-White, Number of Ports 1, Overall Depth 1 7/16 in, Overall Height 11/16 in, Overall Width 5/8 in, Resistance Properties Flame/Fire Resistant, Standards ANSI/TIA-568.2-D, IEC 60603-7, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt Type 3 and Type 4, ISO 11801, RoHS Compliant, UL 1863, UL 2043
