This item is Discontinued.

Panduit Jack, Mini Com, Cat 6, Off White CJ688TPIW

Jack, Mini Com, Cat 6, Off White (Discontinued)

  • Mfr # CJ688TPIW
  • Zoro # G0356641
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
CJ688TPIW
Zoro #
G0356641
UPC #
074983992737
Country of Origin
United States

Dimensions

Depth
1.432 in
Width
0.624 in
Height
0.712 in
Overall Length (In.)
1.43
Overall Width (In.)
0.63
Overall Depth (In.)
1.43
Overall Height (In.)
0.71
Overall Height (mm)
18
Overall Length (mm)
36.3
Overall Width (mm)
16
Overall Depth (mm)
36.3
Overall Width
5/8 in
Overall Depth
1 3/8 in
Overall Height
3/4 in

Details

Item
Modular Jack
Series
Mini Com
Cable Type
CAT6
Material
Plastic
Color
Off-White
For Use With
Mini-Com Faceplate and Panels
Number of Ports
1
Termination Type
Tool-Less
Connector Type
Jack Module - Standard
Minimum Storage Temperature (°C)
-40
Maximum Operating Temperature (°C)
65
Shield Type
Unshielded (UTP)
Module Type
Mini-Com®
Termination Style
TP Style
Minimum Operating Temperature (°C)
-10
Maximum Storage Temperature (°C)
70
Wiring Scheme
T568A/T568B
Product Type
Jack Module
Standards Met
Exceeds Channel and Component Requirements of ANSI/TIA-568-C.2 Category 6 and ISO 11801 Class E Standards at Swept Frequencies 1 to 250 MHz, Meets ANSI/TIA-1096-A, Rated for 2500 Cycles with IEEE 802.3af / 802.3at and Proposed 802.3bt Type 3 and Type 4, Meets IEC 60603-7, UL 1863 Approved and RoHS Compliant
Resistance Properties
Flame/Fire Resistant
Performance Level
Category 6
Body Material
ABS
Contact Material
Plated Phosphor Bronze
Product Name
Mini-Com TX6 Plus Modular Insert
Product Color
Off White
Certifications & Standards
TIA/EIA-568-B.2-1
Product Line
Mini-Com
Connector Details
1 x RJ-45 Network Female
Minimum Operating Temperature (°F)
14
Minimum Storage Temperature (°F)
-40
Sub Brand
Pan-Net®
Maximum Operating Temperature (°F)
149
Maximum Storage Temperature (°F)
158
RCA Insulator Color
Off-White
Standards
ANSI/TIA-1096-A, ANSI/TIA-568-C.2, IEC 60603-7, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt Type 3 and Type 4, ISO 11801 Class E, RoHS Compliant, UL 1863
Compatible Connector Type
RJ45
Compatible Cable Performance Category
6

Description

Modular Jack, Termination Type Tool-Less, Compatible Cable Performance Category 6, Compatible Connector Type RJ45, Color Off-White, RCA Insulator Color Off-White, Number of Ports 1, Overall Depth 1 3/8 in, Overall Height 3/4 in, Overall Width 5/8 in, Resistance Properties Flame/Fire Resistant, Standards ANSI/TIA-1096-A, ANSI/TIA-568-C.2, IEC 60603-7, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt Type 3 and Type 4, ISO 11801 Class E, RoHS Compliant, UL 1863
