Lug Compression Connector, 1 AWG Max, 1/2 in Stud, Standard Barrel, Copper, Green

  • Mfr # LCAX1-56-X

  • Zoro # G0773707


product price:  $6.85
/ea

Key Features

For Wire Size
1 AWG
For Conductor Material
Copper
For Stud Size
1/2 in
Material
Copper
Barrel Size
Standard
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
LCAX1-56-X
Zoro #
G0773707
UPC #
7498343512
Country of Origin
Mexico

Dimensions

For Wire Size
1 AWG
For Stud Size
1/2 in
Barrel Size
Standard
Tongue Width
0.76 in
Width
0.76 in
Cable Size
1 AWG
Length
1.72 in
Overall Length
1.72 in
Barrel Length (In.)
0.66
Class G Copper Flex Conductor Size (AWG)
1
Overall Length (mm)
43.7
DLO Copper Flex Conductor Size (AWG)
1
Tongue Width (mm)
19.3
Tongue Width (In.)
0.76
Outer Diameter (In.)
0.52
Stud Hole Size (mm)
7.9
Tongue Thickness (In.)
0.12
Inside Diameter (In.)
0.39
Wire Strip Length (In.)
44989
Outer Diameter (mm)
0.2
Barrel Length (mm)
16.8
Class M Copper Flex Conductor Size (AWG)
1
Class I Copper Flex Conductor Size (AWG)
1
Inside Diameter (mm)
9.9
Copper Code Conductor Size (AWG)
1
Overall Length (In.)
1.72
Class K Copper Flex Conductor Size (AWG)
1
Tongue Thickness (mm)
3
Stud Hole Size (In.)
45062
Class H Copper Flex Conductor Size (AWG)
1
Wire Strip Length (mm)
19.1

Details

Item
Lug Compression Connector
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
11
Color Code
Green
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connector Type
Standard Barrel
Connection Type
1 x Terminal
Connection Material
Tin
Features
Corrosion Resistant, Angled Connector
Maximum Voltage (kV)
35
Burndy Die Index Number
11
Base Material
Copper
Tongue Type
Standard
Panduit Die Index Number
P37
UL Temperature Rating (°C)
90
T & B Die Index Number
11
Product Type
Copper Compression Connectors - Lugs
Lug Type
1 Stud Hole Lug
Finish/Coating
Tin-Plated
Product Material
Copper
Connector Details
1 x Terminal
Product Name
Terminal Connector
Connector Plating
Tin
Product Class
Lugs, Splices, Split Bolts & Accessories

Description

Lug Compression Connector,No.1 AWG

Restrictions
