  11. Lug Compression Connector, 1/0 AWG Max, Standard Barrel, Copper, Pink
Panduit Lug Compression Connector, 1/0 AWG Max, Standard Barrel, Copper, Pink LCAN1/0-56-X - main

Lug Compression Connector, 1/0 AWG Max, Standard Barrel, Copper, Pink

  • Mfr # LCAN1/0-56-X

  • Zoro # G0426375

product price: $9.99
/ea

Key Features

For Wire Size
1/0 AWG
For Conductor Material
Copper
Material
Copper
Barrel Size
Standard
Tongue Width
0.52 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCAN1/0-56-X
Zoro #
G0426375
UPC #
7498360334
Country of Origin
Mexico

Dimensions

For Wire Size
1/0 AWG
Barrel Size
Standard
Tongue Width
0.52 in
Length
2.02"
Width
0.52"
Cable Size
1/0 AWG
Overall Length
2.02 in
Stud Hole Size (In.)
45062
Tongue Thickness (In.)
0.15
Barrel Length (In.)
0.94
Stud Hole Size (mm)
7.9
Wire Strip Length (In.)
1
Tongue Width (In.)
0.52
Wire Strip Length (mm)
25.4
Tongue Thickness (mm)
3.3
Tongue Width (mm)
13.2
Copper Code Conductor Size (AWG)
36526
Overall Length (mm)
50.8
Barrel Length (mm)
23.9
Overall Length (In.)
2.02

Details

Item
Lug Compression Connector
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
12
Color Code
Pink
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connector Type
Standard Barrel
Connection Material
Tin
Connection Type
1 x Terminal
Features
Angled Connector, Corrosion Resistant
Tongue Type
Narrow
Finish/Coating
Tin-Plated
Burndy Die Index Number
12
Base Material
Copper
Maximum Voltage (kV)
35
UL Temperature Rating (°C)
90
Panduit Die Index Number
P42
Product Type
Copper Compression Connectors - Lugs
Connector Plating
Tin
Connector Details
1 x Terminal
Product Material
Copper
Product Name
Terminal Connector
Product Class
Wire Termination

Description

One-hole, standard barrel with window, narrow tongue lug, 1/0 AWG wire, 5/16 stud hole.
