Shop PANDUIT

Lug Compression Connector, 2 AWG Max, Standard Barrel, Copper, Brown

  • Mfr # LCAX2-38-E

  • Zoro # G0773871

product price:  $6.55
/ea
Sold in multiples of 2 for $13.10

Key Features

For Wire Size
2 AWG
For Conductor Material
Copper
Material
Copper
Barrel Size
Standard
Tongue Width
0.70 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LCAX2-38-E
Zoro #
G0773871
UPC #
7498344267
Country of Origin
Mexico

Dimensions

For Wire Size
2 AWG
Barrel Size
Standard
Tongue Width
0.70 in
Width
0.7"
Cable Size
2 AWG
Length
1.7"
Overall Length
1.7 in
Tongue Thickness (In.)
0.11
Stud Hole Size (mm)
9.5
Tongue Width (In.)
0.7
Class H Copper Flex Conductor Size (AWG)
2
Class M Copper Flex Conductor Size (AWG)
2
Copper Code Conductor Size (AWG)
2
Outer Diameter (mm)
11.93
Overall Length (mm)
43.2
Class K Copper Flex Conductor Size (AWG)
2
Class G Copper Flex Conductor Size (AWG)
2
Inside Diameter (mm)
9.14
Class I Copper Flex Conductor Size (AWG)
2
Wire Strip Length (mm)
17.5
Wire Strip Length (In.)
45246
DLO Copper Flex Conductor Size (AWG)
2
Tongue Thickness (mm)
2.8
Stud Hole Size (In.)
44993
Barrel Length (In.)
0.59
Overall Length (In.)
1.7
Inside Diameter (In.)
0.36
Tongue Width (mm)
17.8
Barrel Length (mm)
15
Outer Diameter (In.)
0.47

Details

Item
Lug Compression Connector
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
10
Color Code
Brown
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connector Type
Standard Barrel
Connection Type
1 x Terminal
Connection Material
Tin
Features
Corrosion Resistant, Angled Connector
Burndy Die Index Number
10
Finish/Coating
Tin-Plated
Base Material
Copper
UL Temperature Rating (°C)
90
Maximum Voltage (kV)
35
Lug Type
1 Stud Hole Lug
Tongue Type
Standard
Panduit Die Index Number
P33
Product Type
Copper Compression Connectors - Lugs
T & B Die Index Number
10
Product Name
Terminal Connector
Product Material
Copper
Connector Plating
Tin
Connector Details
1 x Terminal
Product Class
Lugs, Splices, Split Bolts & Accessories

Description

Lug Compression Connector,No.2 AWG

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
