  11. Lug Compression Connector, 2/0 AWG Max, Standard Barrel, Copper, Black
Panduit Lug Compression Connector, 2/0 AWG Max, Standard Barrel, Copper, Black LCA2/0-12H-X - main

Lug Compression Connector, 2/0 AWG Max, Standard Barrel, Copper, Black

  • Mfr # LCA2/0-12H-X

  • Zoro # G0632665

product price: $11.33
/ea

Key Features

Cable Size
2/0 AWG
Connector Type
Standard Barrel
Width
0.85"
Material
Copper
Length
2.08"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCA2/0-12H-X
Zoro #
G0632665
UPC #
7498355854
Country of Origin
Mexico

Dimensions

Cable Size
2/0 AWG
Width
0.85"
Length
2.08"
Overall Length
2.08 in
Barrel Length (mm)
24.9
Copper Code Conductor Size (AWG)
36557
Barrel Length (In.)
0.98
Wire Strip Length (mm)
27
Tongue Thickness (In.)
0.13
Wire Strip Length (In.)
1.06
Tongue Width (mm)
21.6
Stud Hole Size (In.)
42.767
Overall Length (In.)
2.08
Tongue Thickness (mm)
3.3
Tongue Width (In.)
0.85
Stud Hole Size (mm)
12.7
Overall Length (mm)
52.8
Barrel Size
Standard
Tongue Width
0.85 in
For Wire Size
2/0 AWG

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Black
Item
Lug Compression Connector
Die Code
13
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connection Type
1 x Terminal
Connection Material
Tin
Features
45° Angled Connector, Corrosion Resistant
Maximum Voltage (kV)
35
Burndy Die Index Number
13
Finish/Coating
Tin-Plated
Base Material
Copper
Tongue Type
Standard
Product Type
Copper Compression Connectors - Lugs
Tongue Angle
45 Degrees Angled
Panduit Die Index Number
P45
Product Material
Copper
Connector Details
1 x Terminal
Connector Plating
Tin
Product Name
Terminal Connector
Product Class
Wire Termination
For Conductor Material
Copper

Description

One-hole, standard barrel with window lug, 2/0 AWG wire, 45° angle tongue, 1/2 stud hole.
